34 | English

Note: When the locking lever is fully loosened, gravity

causes the saw blade to tilt into a position that corresponds

to approximately 30°.

– Pull or push the hand wheel (18) along the slotted link un-

til the angle indicator (59) shows the required bevel

angle.

– Hold the hand wheel in this position and retighten the

locking lever (16).

For quick and precise setting of the standard bevel

angles of 0° and 45°, there are pre-set stops ((24)),((22)).

Setting mitre angles (angle guide) (see figure B)

The mitre angle can be set between 30° (left-hand side) and

30° (right-hand side).

– Loosen the locking knob (60) if it is tightened.

– Turn the angle guide until the angle indicator (61) shows

the required mitre angle.

– Retighten the locking knob (60).

Extending the saw table

The free end of long and heavy workpieces must have some-

thing placed underneath it or be supported.

Saw table expansion (see figureC)

The saw table expansion (10) increases the width of the saw

table (4) on the right to a maximum of 950mm.

– Pull the clamping handle (20) for the saw table expansion

all the way up.

– Pull out the saw table expansion (10) to the required

length.

– Push the clamping handle (20) down. This fixes the saw

table expansion in place.

Adjusting the parallel guide

The parallel guide(9) can be positioned on the left or the

right of the saw blade. The marking in the magnifying

glass(62) indicates the set distance of the parallel guide to

the saw blade on the scale(1).

Position the parallel guide on the required side of the saw

blade(see "Fitting the parallel guide (see figure f)",

page32).

Adjusting the parallel guide

when the saw table is not pulled out

– Loosen the clamping handle(43) of the parallel

guide(9). Move the parallel guide until the marking in the

magnifying glass(62) indicates the required distance

from the saw blade.

When the saw table is not pulled out, the marking on the

scale(1) applies.

– To secure it in place, push the clamping handle(43) back

down.

Adjusting the parallel guide

when the saw table is pulled out (seefigureD)

– Position the parallel guide on the right of the saw blade.

Move the parallel guide until the marking in the magnify-

ing glass(62) shows(1) 28cm on the lower scale.

To secure it in place, push the clamping handle(43) back

down.

– Pull the clamping handle(20) for the saw table expansion

all the way up.

– Pull out the saw table expansion(10) until the spacing

indicator(63) shows the required distance from the saw

blade on the scale(2).

– Push the clamping handle(20) down.

This fixes the saw table expansion in place.

Adjusting the additional parallel guide (see

figure E)

To saw narrow workpieces and bevel angles, you must fit

the additional parallel guide(47) on the parallel guide(9).

The additional parallel guide can be fitted on the left or right

of the parallel guide(9) as required.

When sawing, workpieces can become jammed between the

parallel guide and the saw blade, caught in the saw blade as

it rises and ejected.

You should therefore set the additional parallel guide so that

the end of the guide is between the front tooth of the saw

blade and the front edge of the riving knife.

– To do so, loosen all of the fastening set's wing nuts(48)

and move the additional parallel guide accordingly.

– Retighten the wing nuts.

Start-up

u Pay attention to the mains voltage. The voltage of the

power source must match the voltage specified on the

rating plate of the power tool.

u Products that are only sold in AUS and NZ: Use a resid-

ual current device (RCD) with a nominal residual current

of 30 mA or less.

Switching on (see figure F1)

– Fold up the safety flap (19).

– To start, press the green "on" button (25).

– Drop the safety flap (19) back down.

Switching off (see figure F2)

– Press the safety flap (19).

Overload protection

The power tool is equipped with an overload protection sys-

tem. In normal conditions of use, the power tool cannot be

overloaded. In the event of overloading, the power tool auto-

matically shuts off the electronics.

Follow these steps to restart the power tool:

– Allow the power tool to cool down for at least ten minutes.

– Press the restart button(26) and then switch the power

tool back on.

Power outage

The on/off switch acts as a zero-voltage switch that prevents

the power tool from starting up again following a power out-

age (e.g. if the mains plug is removed during operation).

To restart the power tool following a power outage, press the

green "on" button (25) again.

1 609 92A 72F | (13.10.2021) Bosch Power Tools
