surface.

■ Use the four base lock screws (supplied) to mount the

planer base onto the wood.

STOCK REST

See gure 7.

■ The stock rest on the top of the planer provides

convenient handling of stock for consecutive cutting

operations. Stock placed on the top of the machine

can be easily pulled to the operator for planing.

OPERATION

ON / OFF SWITCH

See gure 8.

■ To turn on the planer, push the I button. To turn off,

push the O button.

WARNING

Always be sure the switch is in the OFF position before

connecting the planer to the power source.

CIRCUIT OVERLOAD SWITCH

See gure 8.

■ The machine is provided with an overload switch for

overload protection. If an overload occurs, the switch

will pop out. If this happens, wait several minutes and

press the switch to reset the machine.

ADJUSTING DEPTH OF CUT

See gure 9.

WARNING

Never plane more than 3 mm in one pass and never

attempt to plane a board under 127 mm (5") in length.

Always wear a protective face shield.

■ To adjust the depth of cut, turn the cutterhead height

adjustment crank handle in the directions marked on

top of the planer. The depth of cut adjustment can

be read from the depth of cut scale. The adjustment

gradation is 1.6 mm per revolution of the crank.

■ Always start your work by making a light planing

cut. The depth of cut on subsequent passes may be

increased by up to 3 mm, but remember that a light cut

creates a finer finish than a heavier cut.

■ The thickness of timber running through the planer is

controlled by the distance you adjust the cutting blade

from the table.

• Do not plane timber that is less than 7 mm thick.

• Do not plane timber that is thicker than 153 mm

(6").

ADJUSTING THE DEPTH OF CUT SCALE

See gure 9.

For the safe operation of your planer, it is very important

that the depth of cut scale reads accurately. To adjust the

depth of cut scale, follow the steps below:

■ Feed a board for planing.

Compare the measured thickness of the board to the

reading on the depth of cut scale.

■ If the reading on the depth of cut scale is incorrect,

loosen the screw which tightens the plastic pointer and

adjust accordingly.

■ When you have properly adjusted the depth of cut

scale, test the reading by planing a piece of scrap

timber. After planing, measure the planed thickness

and double check it against the scale reading. The

two measurements should be the same. Re-adjust

the depth of cut scale to read the planed thickness if

necessary.

REMOVING THE PLANER BLADES

See gure 10-12.

To remove the planer blades, follow the steps below:

WARNING

Unplug your planer from the power source before

removing the planer blades.

■ Remove the dust chute by removing the four hexagonal

socket head cap screws on it.

■ Loosen the lock bar and blade by turning the forcing

screws clockwise. The blades are spring loaded, and

will push out when the assembly is loosened.

■ Take out the blade, and then the blade lock bar.

INSTALLING / REPLACING THE PLANER BLADES

See gure 12.

To install the planer blades, follow the steps below:

■ Remove the blades according to the instructions in

"REMOVING THE PLANER BLADES".

■ Clean away all debris from the planer cutterhead.

■ Fit the blade lock bar into the slot on the cutterhead.

■ Fit the blade into the slot on the cutterhead, and

tighten the lock bar blade assembly by turning the

forcing screws counter clockwise. Make sure the blade

is facing the correct direction and is centred in the slot.
