English 21
4. Install the wiper cloth, see chapter Installing the wip-
er cloth.
5. Press the On/Off button.
Cleaning continues.
transport
Where possible, always transport or return the device in
the original packaging. Please contact our Service De-
partment if the original packaging is not available.
Safety instructions for transporting
The lithium-ion battery is subject to the requirements of
dangerous goods regulations.
An undamaged and functional battery pack can be
transported by the user in public traffic areas without
any further restrictions.
When shipping by third parties (transport companies),
special requirements for packaging and labelling must
be observed.
Observe the national regulations.
Storage
ATTENTION
Damage to the cleaning robot due to incorrect stor-
age
Do not store the cleaning robot upside down. The hous-
ing of the laser radar (LiDAR) should never come into
contact with the ground or objects.
Do not place any objects on the cleaning robot.
Store the cleaning robot fully charged and switched off
in a cool and dry place.
Note
To avoid a deep discharge of the battery, fully recharge
the cleaning robot after 5 months at the latest.
1. Clean the cleaning robot, see chapter Cleaning.
2. Fully charge the cleaning robot, see chapter Manu-
ally sending the cleaning robot for recharging.
3. Unplug the charger from the mains socket and the
station.
4. Switch off the cleaning robot, see chapter Switching
off the cleaning robot.
5. Store the cleaning robot in a cool and dry place.
Care and service
Cleaning
Cleaning the dust container
1. Press any button.
The cleaning robot stops.
2. Remove the dust container see chapter Removing
the dust container.
3. Empty the dust container, see chapter Emptying the
dust container.
ATTENTION
Damage to electronic components
Do not clean the dust container with water.
4. Clean the dust container with the cleaning tool sup-
plied.
Illustration P
5. Close the filter flap.
6. Install the dust container, see chapter Installing th
e
dust cont
ainer.
7. Press the On/Off button.
Cleaning continues.
Cleaning the water reservoir
1. Press any button.
The cleaning robot stops.
2. Remove the water reservoir, see chapter Removing
the water reservoir.
3. Turn the water reservoir upside down and empty it.
4. Clean the water reservoir.
5. Push the water reservoir horizontally into the clean-
ing robot until it audibly latches into place.
Illustration G
6. Press the On/Off button.
Cleaning continues.
Cleaning the filter
We recommend cleaning the filters regularly. This pre-
vents them from becoming clogged.
1. Press any button.
The cleaning robot stops.
2. Remove the dust container see chapter Removing
the dust container.
3. Remove the filter.
Illustration Q
a Press the clamp.
b Open the cover.
c Remove the filter.
4. Clean the filter under running water with the clean-
ing tool supplied.
5. Allow the filter to dry completely.
6. Install the filter.
Illustration R
a Press the filter into position.
b Close the cover of the dust container.
7. Install the dust container, see chapter Installing the
dust container.
8. Press the On/Off button.
Cleaning continues.
Cleaning the brush
1. Remove the brush.
Illustration S
a Press the clamps together.
b Remove the brush cover.
c Remove the brush.
d Remove the brush bearing.
2. Clean the brush and brush bearing with the cleaning
tool supplied.
3. Install the brush.
Illustration T
a Fit the brush bearing.
b Fit the brush.
c Fit the brush cover and press it down until it audi-
bly latches into place.
Cleaning the side brush
1. Remove the side brush.
Illustration U
2. Clean the side brush.
3. Install the side brush.
Cleaning the fall sensors
Clean the fall sensors monthly.
Illustration V
1. Wipe the fall sensors with a soft cloth.
Cleaning the 3-D sensor
Dirt and dust on the 3-D sensor can affect the obstacle
detection of the cleaning robot.
Illustration W
1. Wipe the 3D sensor with a soft, dust-free cloth.
