16

Список деталей: рычажная таль

JLPА/B № № детали обозначение

размер кол-во

30 ....... JLP150-30 ............ Chain Stop .............................................. ................................ 1

31 ....... JLP150-31 ............ Hex Nut .................................................. M10 .......................... 6

32 ....... JLP150-32 ............ Lock Washer ........................................... 10; ........................... 6

32A ..... JLP150-32A .......... Flat Washer ............................................ 10 ............................. 6

33 ....... JLP150-33 ............ Hex Nut (1-1/2, 3, 6T) ............................. M8 ............................ 2

34 ....... JLP150-34 ............ Lock Washer (1-1/2, 3, 6T) ....................... 8 .............................. 2

34A ..... JLP150-34A .......... Flat Washer (1-1/2, 3, 6T) ........................ 8 .............................. 4

35 ....... JLP150-35 ............ Castle Nut (1-1/2, 3, 6T) .......................... M12 .......................... 1

36 ....... JLP150-36 ............ Split Pin (1-1/2, 3, 6T) ............................. 2.5x25 ...................... 1

37 ....... JLP75-37 .............. Rivet (1/2-6T) ......................................... 2.5x6 ........................ 6

40 ....... JLP150-40 ............ Top Hook Assembly .................................. ................................ 1

........... .......................... Top Hook ................................................ ................................ 1

........... .......................... Safety Latch ............................................ ................................ 1

........... .......................... Double Spring ......................................... ................................ 1

........... .......................... Rivet ...................................................... 4x18 ......................... 1

........... .......................... Top Hook Block ........................................ ................................ 2

........... .......................... Rivet ...................................................... 6x24 ......................... 2

41 ....... JLP150-41 ............ Top Hook Shaft ........................................ ................................ 1

43 ....... JLP150-43 ............ Bottom Hook Assembly ............................. ................................ 1

........... .......................... Bottom Hook ........................................... ................................ 1

........... .......................... Safety Latch ............................................ ................................ 1

........... .......................... Double Spring ......................................... ................................ 1

........... .......................... Rivet ...................................................... 4x18 ......................... 1

........... .......................... Bottom Hook Block ................................... ................................ 2

........... .......................... Rivet ...................................................... 6x24 ......................... 4

43A ..... JLP150-43A .......... Shaft ...................................................... ................................ 1

43C ..... JLP150-43C .......... Nut ........................................................ M8 ............................ 1

43D ..... JLP150-43D .......... Pin ......................................................... 2x16 ......................... 1

50 ....... JLP150-50 ............ Screw (1-1/2, 3, 6T) ................................ M8x16 ....................... 2

51 ....... JLP150-51 ........... Washer(1-1/2, 3, 6T) ............................... M8 ............................ 2

58 ....... JLP150-58 ............ Snap Ring ............................................... 34 ............................. 1

100 ...... JLP150-100 .......... Safety Latch Kit ....................................... ................................ 1

........... .......................... Safety Latch ............................................ ................................ 1

........... .......................... Double Spring .......................................... ................................ 1

........... .......................... Rivet ...................................................... 4x18 ......................... 1

........... 187723 ................ Chain ..................................................... 8mm ......................... 1

Note: Top and bottom hooks are sold as an assembly only.
