17

Список деталей: рычажная таль JLPА/B

№ детали обозначение

размер кол-во

1 ......... JLP300-1 ............... Gear Case Assembly (3, 6T) ...................... ................................ 1

........... .......................... Gear Case .............................................. ................................ 1

........... .......................... Bushing .................................................. ................................ 2

........... .......................... Cover ..................................................... ................................ 1

........... .......................... Rivet ...................................................... 4x6 ........................... 2

2 ......... JLP300-2 .............. Spur Gear Assembly (3, 6T) ...................... ................................ 2

........... .......................... Spur Gear ............................................... ................................ 2

........... .......................... Pinion Gear ............................................. ................................ 2

3 ......... JLP300-3 .............. Drive Shaft (3, 6T) ................................... ................................ 1

4 ......... JLP300-4 .............. Load Gear (3, 6T) .................................... ................................ 1

5 ......... JLP300-5 .............. Gear Side Plate Assembly (3, 6T) ............... ................................ 1

........... .......................... Gear Side Plate ....................................... ................................ 1

........... .......................... Stay Bolt ................................................ ................................ 3

........... .......................... Bushing .................................................. ................................ 2

........... .......................... Race "A" ................................................. ................................ 1

6 ......... JLP300-6 .............. Load Sheave (3, 6T) ................................ ................................ 1

8 ......... JLP800-8 .............. Guide Block (3, 6T) .................................. ................................ 1

9 ......... JLP300-9 .............. Guide Roller (3, 6T) ................................. ................................ 1

10 ....... JLP300-10 ............ Stripper (3, 6T) ....................................... ................................ 1

11 ....... JLP300-11 ............ Roller Kit(24 rollers) (3, 6T) ...................... 5x6 ........................... 1

12 ....... JLP300-12 ............ Bearing Race (3, 6T) ................................ ................................ 1

13 ....... JLP150-13 ............ Pawl Spring (1-1/2. 3. 6T) ........................ ................................ 2

14 ....... JLP150-14 ............ Pawl (1-1/2, 3, 6T) .................................. ................................ 2

15 ....... JLP150-15 ............ Snap Ring (1-1/2, 3, 6T) ........................... ................................ 2

16 ....... JLP300-16 ............ Lever Side Plate Assembly (3, 6T) .............. ................................ 1

........... .......................... Lever Side Plate....................................... ................................ 1

........... .......................... Race "B" ................................................. ................................ 1

........... .......................... Pawl Pin ................................................. ................................ 2

17 ....... JLP300-17 ............ Disc Hub (3, 6T) ...................................... ................................ 1

18 ....... JLP300-18 ............ Spring (3, 6T) ......................................... ................................ 1

19 ....... JLP300-19 ............ Friction Disc (3, 6T) ................................. ................................ 2

20 ....... JLP300-20 ............ Ratchet Disc (3, 6T) ................................. ................................ 1

21 ....... JLP300-21 ............ Feed Gear (3, 6T) .................................... ................................ 1

22 ....... JLP300-22 ............ Brake Cover Assembly (3, 6T) ................... ................................ 1

........... .......................... Brake Cover ............................................ ................................ 1

........... .......................... Handle Case ............................................ ................................ 1

........... .......................... Nut ........................................................ ................................ 2

........... .......................... Bushing .................................................. ................................ 1

23 ....... JLP150-23 ............ Change Over Gear (1-1/2, 3, 6T) ............... ................................ 1

24 ....... JLP150-24 ............ Lever Handle Assembly (1-1/2, 3, 6T) ......... ................................ 1

........... .......................... Lever Handle ........................................... ................................ 1

........... .......................... Selector Lever ......................................... ................................ 1

........... .......................... Change Over Shaft ................................... ................................ 1

........... .......................... Cover ..................................................... ................................ 1

........... .......................... Rivet ...................................................... 3x12 ......................... 1

........... .......................... Bolt ....................................................... ................................ 2

........... .......................... Spring Seat ............................................. ................................ 1

........... .......................... Bushing .................................................. ................................ 1

24A ..... JLP150-24A .......... Rubber Grip ............................................ ................................ 1

25 ....... JLP150-25 ............ Change Over Paw! (1-1/2, 3, 6T) ............... ................................ 1

26 ....... JLP150-26 ............ Spring Shaft (1-1/2, 3, 6T) ........................ ................................ 1

27 ....... JLP150-27 ............ Spring (1-1/2, 3. 6T) ................................ ................................ 1

28 ....... JLP150-28 ............ Hand Wheel (1-1/2, 3, 6T) ........................ ................................ 1

29 ....... JLP300-29 ............ Name Plate ............................................. ................................ 1

30 ....... JLP300-30 ............ Chain Stop (3, 6T) ................................... ................................ 1

31 ....... JLP300-31 ........... Hex Nut (3, 6T) ....................................... M12 .......................... 6
