Hour meters - TBW series

TBW30.18

Front panel mounting

Mounting aperture 50 x 25mm

Without zero reset

12.02– 1

1. Indicators

Counter capacity: 99 999h

Accuracy of reading: 0.01h

Numeral colour: white, decimal figures red

Numeral height: 4.4mm

Operation indicator: fast-running wheel

2. Mechanical design

Self-extinguishing plastic housing, IP rating IP54 (on the front)

Class of protection II

Front panel mounting

Shockproof terminal connection according to VBG 4

(terminals IP rating IP00 / AMP plug-type connections 6.3 x 0.8mm)

Initial torque: max. 2.4Nm

Terminal capacity: cylinder head bolt M3x5, DIN 84

3. Input circuit

Supply voltage: 230V AC

Tolerance: ±10%

Rated frequency: 50Hz

Rated consumption: approx. 1.5VA

4. Ambient conditions

Ambient temperature: -15 to +50°C

Storage temperature: -15 to +50°C

Transport temperature: -15 to +50°C

Relative humidity: <90%

5. Accessories

SB-TBX30: Retaining clip for fixing the device in

front panel aperture

Technical data

Subject to alterations and errors

Release 11/01
