3
English
Slippery handles and grasping surfaces do not
allow for safe handling and control of the tool in
unexpectedsituations.
5) Service
a) Have your power tool serviced by a qualied
repair person using only identical replacement
parts.
Thiswillensurethatthesafetyofthepower toolis
maintained.
PRECAUTION
Keep children and inrm persons away.
When not in use, tools should be stored out of reach of
children and inrm persons.
IMPACT WRENCH SAFETY
WARNINGS
○ Hold the power tool by insulated gripping surfaces,
when performing an operation where the fastener
may contact hidden wiring or its own cord.
Fasteners contacting a “live” wire may make exposed
metal parts of the power tool “live” and could give the
operator an electric shock.
ADDITIONAL SAFETY WARNINGS
1. When using the tool at a hight, make sure that there is
nobody below.
2. Use earplugs if using for a long time use.
3.
Switch the reversing switch only after the motor has stoped
when it is necessary to change the direction of the rotation.
4. Use a step up transformer when a long extension cable
is used.
5. Conrmthetighteningtorquebyatorquewrenchbefore
useinordertoassertainthecorrecttighteningtorqueto
be used.
6. Assemble the socket securely to the impact wrench with
the socket pin and ring.
7. Conrmwhetherthesockethasanycracksinit.
8. Always hold the handle and side handle of the impact
wrench rmly. Otherwise the counterforce produced
may result in inaccurate and even dangerous operation.
SYMBOLS
WARNING
The following show symbols used for the machine. Be
sure that you understand their meaning before use.
WR22SE / WR25SE : Impact Wrench
To reduce the risk of injury, user must read
instruction manual.
OnlyforEUcountries
Do not dispose of electric tools together with
household waste material!
In observance of European Directive 2012/19/EU
onwasteelectricalandelectronicequipmentand
its implementation in accordance with national law,
electric tools that have reached the end of their life
must be collected separately and returned to an
environmentally compatible recycling facility.
SwitchingON
SwitchingOFF
Clockwise rotation
Counterclockwise rotation
Disconnect mains plug from electrical outlet
Class II tool
STANDARD ACCESSORIES
In addition to the main unit (1 unit), the package
contains the accessories listed in the below.
○ Case ...........................................................................1
Standard accessories are subject to change without notice.
APPLICATIONS
○ Tighteningandloosingvariouskindsofboltandnut.
SPECIFICATIONS
Model WR22SE WR25SE
Voltage (by areas)* (110V, 120V, 230V, 240V)
Power input* 800 W 900 W
Noloadspeed/Impact
rate
1400 / 2000 min
-1
1100 / 1500 min
-1
Squaredrive 19 mm 25.4 mm
Capacities
(size of
bolts)
High
tension bolt
M16―M22 M22―M24
Ordinary
bolt
M14―M24 M22―M30
Tighteningtorque
(Max.)**
620N·m 1000N·m
Weight***
5.2 kg 8.4 kg
* Be sure to check the nameplate on product as it is
subject to change by areas.
**
Tightening the bolt without extension cord at rated voltage.
*** Weight: According to EPTA-Procedure 01/2014
NOTE
Due to HiKOKI’s continuing program of research and
development, the specications herein are subject to
change without prior notice.
MOUNTING AND OPERATION
CAUTION
Topreventaccidents,makesuretoturntheswitch o
and disconnect the plug from the receptacle.
Action Figure Page
Mounting the socket (1) 1
81
Mounting the side handle 2
81
Changing the rotation direction 3
81
Dismounting the hook hanger (WR25SE)
4
81
Selecting accessories* ―
83
* Selectaccessoriesthataresuitedtoaspecictask.
FordetailscontactHiKOKIAuthorizedServiceCenter.
0000Book_WR22SE.indb 3 2019/03/05 16:33:36
