Rossvik V-626 автоматический, до 26", 380 В, 2 скорости V-626/380 2sp Деталировка онлайн [4/28] 841986

Rossvik V-626 автоматический, до 26
82
44
39
40
83
79
80
73
55
45
16
11
15
76
60
62
13
35
41
31
57
58
14
24
65
75
74
73
12
7
34 52 77 78 48 52 32
27
26
28
38
48
18
8
48
52
56
51
29
54
49
47 52
46
33
17
49
50
53
2
25
1 9 72
3
21
22
23
20
62 61 60 59
19
4837368467
68
5
4
706930
42
71
6
10
43 66
63
64
81
ITEM PART.No DESCRIPTION. QT.Y
1 C-80-1100000 BODY WELDING 1
2 C-80-1200000 ATTENDANCE 1
3 C-80-1300000 HORIZONTAL ARM 1
4 C-80-1400000 ADJUSTING SLEEVE 1
5 CT-B-9000000 BEAD BREAKER 1
6 CT-C-2100000 BEAD BREAKER BLADE 1
7 C-7C-1000001 PROTECTIVE COVER 1
8 C-80-1000002 GUARD BOARD 1
9 C-80-1000003 RUBBER PAD PLATE 1
10 C-80-1000004 RUBBER PLUG 1
11 CT-J-4100000 GEARBOX ASSEMBLY 1
12 CT-D-4600000 PEDAL ASSEMBLY 1
13 CT-K-1300000 QUICK INFLATION PEDAL ASSY 1
14 CT-XD-1000000 PULL-OUT CYLINDER D80X80 1
15 CT-DJ-0218112 MOTOR ASSEMBLY 1
16 CT-Q-4000000 AIR GUIDER 1
17 C-80-1000007 ROTATION SHAFT 1
18 CT-K-3500000 INFLATOR COVER ASSEMBLY 1
19 CT-K-4100000 AIR TANK 1
20 CT-K-2200000 QUICK EXHAUST VALVE ASSY 1
21 C-80-1000008 ROTATION SHAFT 1
22 C-70-1000008 WASHER 2
23 C-80-1000009 HEXANGULAR BOLT 2
24 C-70-1000004 PIN SHAFT 1
25 C-70-1000006
φ12 RUBBER PLUG
2
26 C-90-1000002 PLUG B 1
27 C-90-1000003 PLUG A 2
28 C-90-1000004 PLUG C 2
29 C-70-1000014 STOP-UP 2
30 CT-C-2100003 WASHER 1
31 C-70-1000021 INNER HEXA CYLINDRICAL TERMINUS SET SCREW 2
32 C-54-1000005 RUBBER FOOT 4
33 CT-Q-0000001 CLAMP RING 2
34 C-90-1000012 PROTECTIVE ROD 1
35 C-70-1000011 SEALED COVER 1
36 C-90-1000013 AIR REGULATOR BRACKET 1
37 CT-F-2122111 AIR REGULATOR ASSEMBIY 1
38 CT-LS-D000000 BEAD BREAKER CYLINDER ASSEMBLY 1
39 CT-Y-5700000 TURNTABLE ASSEMBLY 1
40
GB1096-C12×8×45
COMMON FLAT KEY 1
41 GB6172.- M14 HEXANGULAR THIN NUT 2
42 CT-B-2000002 SPRING 1
43 CH-34-1000001 PRESSURE LIMIT VALVE 1
44 CT-Y-0100001 PRESS COVER 1
45 CT-DJ-0000007 BELT A-25 1
ITEM PART.No DESCRIPTION. QT.Y
46 C-80-1000001 SIDE PANEL 1
47
GB70.1-M6×12
INNER HEXA CYLINDRICAL SCREW 5
48
GB70.1-M6×10
INNER HEXA CYLINDRICAL SCREW 10
49 GB93-12 STANDARD SPRING WASHER 8
50 GB6172.1-M12 HEXANGULAR THIN NUT 2
51 C-70-1000005 BOLT 2
52 GB95-6 FLAT WASHER 13
53 GB95-12 FLAT WASHER 6
54
GB5782-M12×65
HEXANGULAR BOLT 6
55 GB41-M10 HEXANGULAR NUT 16
56
GB5781-M10×35
HEXANGULAR BOLT 2
57
GB70.1-M12×50
INNER HEXA CYLINDRICAL SCREW 1
58 GB889.1-M12 1-TYPE PREVAILING TORQUE TYPE HEXAGON LOCK NUT 1
59
GB/T 5781-2000 - M8×25
HEXANGULAR BOLT 2
60 GB95-8 FLAT WASHER 4
61 GB93-8 STANDARD SPRING WASHER 4
62 GB41-M8 HEXANGULAR NUT 4
63 GB95-5 FLAT WASHER 2
64
GB5781-M5×12
HEXANGULAR BOLT 1
65 GB894.1-12 SHAFT ELATIC BIG RETAINING RING A-TYPE 2
66 FPC 8-01 MALE STRAIGHT 2
67
GB5782-M16×120
HEXANGULAR BOLT 1
68 GB889.1-M16 1-TYPE PREVAILING TORQUE TYPE HEXAGON LOCK NUT 1
69 GB955-14 WAVE-FORM SPRING WASHER 1
70 GB889.1-M14 1-TYPE PREVAILING TORQUE TYPE HEXAGON LOCK NUT 1
71 C-54-1300011 RUBBER COVER 1
72
GB70.1-M6×16
INNER HEXA CYLINDRICAL SCREW 6
73 GB95-10 FLAT WASHER 16
74 GB93-10 STANDARD SPRING WASHER 2
75
GB70.1-M10×25
INNER HEXA CYLINDRICAL SCREW 2
76
GB5783-M8×20
HEXANGULAR BOLT 2
77 GB93-6 STANDARD SPRING WASHER 5
78 GB41-M6 HEXANGULAR NUT 2
79 GB96.1-10 LARGE WASHER A GRADE 6
80 GB5781-M10X200 BOLT M10X200 4
81
GB/5781-M10×160
HEXANGULAR BOLT 2
82
GB70.1-M12×30
INNER HEXA CYLINDRICAL SCREW 1
83
GB70.1-M6×35
INNER HEXA CYLINDRICAL SCREW 2
84
GB70.1-M4×10
INNER HEXA CYLINDRICAL SCREW 4
85 C-70-1000018 JOINT SEALING GASKET 2
86 FPLF 8-02 FEMALE ELBOW 2
87 FPC 8-02 MALE STRAIGHT 2
88 FPY-8 UNION Y 2
89 C-01-1000004 CABLE CONNECTOR 1
REVISION A-01
C-80-1000000
7.
