Rossvik V-626 автоматический, до 26", 380 В, 2 скорости V-626/380 2sp Деталировка онлайн [5/28] 841986

1022 9

ITEM PART.No DESCRIPTION. QT.Y

1 C-80-1310000 COLUMN WELDING DRAWING 1

2 C-80-1320000 HORIZONTAL ARM 1

3 C-80-1330000 LOCKING CYLINDER ASSY 1

4 C-80-1300001 SQUARE LOCK PLATE 1

5 C-80-1300002 PRESS SPRING 2

6 C-80-1300006 PROTECTION COVER 1

7 C-90-1200004 OIL CUP 1

8 C-90-1200005 PROTECTIVE HOOD LOCK BUSHING 2

9 C-90-1200006 CUSHION 2

10 C-90-1200007 RUBBER WASHER 1

11 C-90-1200008 AIR HOSE CHUTE 1

12 C-90-1200013 BLOCK PLATE 1

13 C-60-1000002 INFLATING GUN HOOK 1

14 C-70-1200010 INNER HEXA FLAT TERMINUS SET SCREW 1

15 GB41-M8 HEXANGULAR NUT 1

16 GB95-8 FLAT WASHER 2

17 GB93-8 STANDARD SPRING WASHER 2

GB70.1-M8×30

INNER HEXA CYLINDRICAL SCREW 2

GB77-M8×16

INNER HEXA FLAT TERMINUS SET SCREW 2

20 GB6172.1-M8 HEXANGULAR THIN NUT 2

GB6173-M10×1.0

HEXA THIN NUT 1

GB5781- M8×20

HEXANGULAR BOLT 1

GB79-M12×50

INNER HEXA CYLINDRICAL TERMINUS SET

SCREW

24 GB6172.1-M12 HEXANGULAR THIN NUT 2

GB70.1-M6×10

INNER HEXA CYLINDRICAL SCREW 2

GB818-M6×40-H

CROSS PANHEAD SCREW 2

27 C-80-1300003 TELEFLEX BASE 1

28 C-80-1300004 TELEFLEX 1

GB119.2-10×50

CYLINDRICAL PIN 1

版本 A-01

C-80-1300000
