16
be observed under all circumstances.
- Harmful/toxic dusts can be produced during your
work (e.g. lead-containing paint, some types
of wood and metal). Contact with these dusts,
especially inhaling them, can represent a hazard
for operating personnel or persons in the vicinity.
Comply with the safety regulations that apply in
your country. Connect the electric power tool to a
suitable extraction system. To protect your health,
wear a P2 protective mask.
- Never use machines with a damaged cable. Do
not touch damaged cables and pull the plug
from the mains power supply if the cable be-
comes damaged during work. Damaged cables
increase the risk of electric shock.
- Use a maximum of two extension pipes on the
machine.
- Only for AS/NZS: The tool shall always be sup-
plied via residual current device with a rated
residual current of 30 mA or less.
5.3 Emission levels
Levels determined in accordance with EN 60745
are typically:
Sound pressure level 82 dB(A)
Noise level 93 dB(A)
Measuring uncertainty allowance K = 3 dB
CAUTION
The noise produced during work may damage
your hearing.
• Wear ear protection!
Overall vibration levels (vector sum for three di-
rections) measured in accordance with EN 60745:
Vibration emission level
(3-axis) a
h
< 2.5 m/s
2
Uncertainty K = 3 m/s²
The specifi ed emissions values (vibration, noise)
– are used to compare machines.
– They are also used for making preliminary es-
timates regarding vibration and noise loads
during operation.
– They represent the primary applications of the
power tool.
Increase possible for other applications, with oth-
er insertion tools or if not maintained adequately.
Take note of idling and downtimes of machine!
6 Commissioning
WARNING
Risk of accident if the machine is operated using
unauthorised voltages or frequencies.
-
The mains voltage and the frequency of the
power source must correspond with the speci-
fi cations on the machine’s name plate.
- In North America, only Festool machines with
voltage specifi cations of 120 V may be used.
The switch [5-2] is an on/off switch (I = ON, 0 =
OFF). Connecting and detaching the mains power
cable [1-5], see Fig. [4].
7 Machine settings
WARNING
Risk of accident, electric shock
Always pull the plug out of the socket before
performing any type of work on the machine.
7.1 Fitting the PLANEX
Hold the sanding head [1-1] with the sanding
pad facing downwards.
If closed, release the clamping levers [2-1] and
[2-2].
Slide the extension pipe [1-2] into the opening
up to the stop as illustrated in [2].
Close the clamping levers [2-1] and [2-2].
Slide the contact slide [3-2] into the retainer as
illustrated in [3].
Press the contact slide down until it latches
into position.
Insert the handle section [1-3] at the same
time.
If you wish to use the PLANEX for sanding
walls in cramped spaces, for example, reduce
the length of the machine by fi tting the sanding
head [1-1] directly to the handle section [1-3].
When disassembling the machine, do not forget
to press the button [3-1] to release the contact
slide before opening clamping levers [2-1] and
[2-2].
7.2 Electronics
The machine features full-wave electronics with
the following properties:
Smooth start-up
The electronically controlled smooth start-up func-
tion ensures that the machine starts up smoothly.
