ENGLISH

SEWING A BUTTONHOLE MANUALLY

1. Put the cloth under the presser foot and lower the presser foot on the cloth where you need to

sew buttonhole, then choose the stitch pattern #8.

2. Turn on the switch and sew 5-6 stitch in low speed, then turn off the switch (Fig. 1).

3. Choose the stitch pattern #7, turn on switch and sew on the cloth in suitable length, then turn off

switch. Note that try to keep sewed stitch in straight line (Fig. 2).

4. Choose thestitchpattern#8, then turn on switch and sew 5-6 stitch in low speed, then turn off

switch (Fig. 3).

5. Raise the presser foot, rotating the cloth for 180° ( Fig.4)

6. Choose the stitch pattern #7, then turn on switch and sew till buttonhole is fully sewed. (Fig. 5)

TROUBLESHOOTING

Problem Problem cause Amendment

No power or the

machine runs slowly

Batteries are installed

incorrectly

Reinstall the batteries making sure they

are the oorrect way around

Batteries are low Use new batteries

Adaptor power inadequate Use compatible adaptor

Skipping stitches Needle eye not in the middle Remove and re-insert the needle with

the at side of the needle to the back

Needle bent Remove and re-insert a new needle

Presser foot too loose Tighten the presser foot

Bobbin thread cannot

be drawn up

Lower thread has been used up Replace with new full bobbin

Needle threaded incorrectly Re-thread the needle, making sure it is

threaded from the front to the back

Thread keeps breaking Needle bent Remove and re-insert a new needle

Needle shank not properly

seated

Remove and re-insert a new needle

Thread tension dial, thread

guide or thread pulling bar too

tight

Loosen the thread tension between 3-5

number

Stitches too loose or

uneven

Thread blocked by upper

bobbin

Pull out the spool pin and make the

bobbin or thread run smoothly

Upper thread too loose

Needle breaks Needle bent or deformed Remove and re-insert a new needle

WORK LIGHT

If additional light is needed,press the light switch to turn the light‘ On‘. Press the

switch again to turn it‘Off‘.

SEWING SLEEVES

This sewing machine has been designed to sew sleeves or any narrow

openings in garment .

1. Lift the presser foot.

2. Position the garment over the sewing arm.

3. Lower the presser foot and follow the regular sewing instructions.

DRAWER

On the side of the sewing machine (towards the rear) is a drawer for the handy

storage of accessories

BOBBIN WINDING

1. Put a spool of thread on spool pin (Fig.1).

2. Place the thread to the right of the bobbin winder tension disk (Fig. 2)

3. Push the bobbin into the bobbin winder pin and push it to the left. (Fig. 3)

4. Wind thread clockwise around bobbin several times.

5. Open the speed switch to start winding.(Fig. 4)

6. Stop winding after correct volume ofthread is winded on bobbin. (Fig. 5)

7. Take bobbin off the spindle and cut the thread.

FEATURES

ADJUSTING STITCHING

1. As shown in the picture (Fig. 1) normal stitching shall

be neat with top and bottom threading neither too tight nor

too loose.

2. If the bottom threading looks like a straight line, which

indicates the top thread is too loose. Please turn too tight

nor too loose clock wise to increase pressure until the

stitching returns to normal. (Fig. 2)

3. However, when the top thread looks like a straight line

indicating an over-tight top thread, slowly turn the upper

thread tension dial counterclockwise to reduce pressure until the stitching back to normal. (Fig. 3)
