Деталировка

установки фильтрации воздуха Powermatic PM1200

№ Артикул Описание Размер Кол-во

1 ................. 1791083 ...................... Outer Filter for PM1200 ................................................ 12”x24”x1” ....................... 1

2 ................. 1791082 ...................... Inner Filter for PM1200 ................................................ 12”x24”x1” ....................... 1

3 ................. PM1200-03 .................. Retaining Plate ............................................................. ........................................ 1

4 ................. PM1200-04 .................. Rivet ............................................................................. NSS 4-4 ........................... 2

5 ................. PM1200-05 .................. Eye Bolt * ..................................................................... M6 ................................... 4

6 ................. TS-1540041 ................ Hex Nut * ...................................................................... M6 ................................... 4

7 ................. TS-1550041 ................ Flat Washer * ............................................................... M6c4 .................................

8 ................. TS-1534032 ................ Phillips Pan Head Machine Screw ............................... M6x8 ............................... 4

9 ................. PM1200-09 .................. Special Nut ................................................................... M6 ................................... 4

10 ............... TS-1550041 ................ Flat Washer .................................................................. M6 ................................... 6

11 ............... TS-1551041 ................ Lock Washer ................................................................ M6 ................................... 6

12 ............... TS-1503031 ................ Socket Head Cap Screw .............................................. M6x12 ............................. 6

13 ............... PM1200-13 .................. Diffusion Filter .............................................................. ........................................ 1

14 ............... PM1200-14 .................. Filter Guard (re: PM1200-14A) ..................................... ........................................ 2

15 ............... PM1200-15 .................. Short Chrome Strip (re: PM1200-14A) ......................... ........................................ 4

................... PM1200-14A ............... Filter Guard Assembly (includes #14 and 15) .............. ........................................ 1

16 ............... PM1200-16 .................. Cabinet ......................................................................... ........................................ 1

................... PM1200-16A ............... Cabinet Assembly (includes #3, 4, 9 and 16) ............... ........................................ 1

17 ............... PM1200-17 .................. Control Switch Assembly ............................................. ........................................ 1

17-1 ............ PM1200-1701 .............. Circuit Board Assembly ................................................ ........................................ 1

17-2 ............ TS-1540031 ................ Hex Nut ........................................................................ M5 ................................... 2

17-3 ............ PM1200-1703 .............. Toothed Washer .......................................................... M5 ................................... 2

17-4 ............ PM1200-1704 .............. Switch Plate ................................................................. ........................................ 1

17-5 ............ TS-1531012 ................ Counter Sunk Screw .................................................... M3x6 ............................... 4

17-6 ............ PM1200-1706 .............. Control Switch Label .................................................... ........................................ 1

17-7 ............ PM1200-1707 .............. Thermos Switch ........................................................... 5A .................................... 1

17-8 ............ TS-1533042 ................ Phillips Pan Head Machine Screw ............................... M5x12 ............................. 1

17-9 ............ PM1200-1709 .............. Wiring Nut .................................................................... P2 .................................... 1

17-10 .......... PM1200-1710 .............. Strain Relief ................................................................. ........................................ 1

17-11 .......... PM1200-1711 .............. Power Cord .................................................................. 18AWGx3C ..................... 1

18 ............... PM1200-18 .................. Tapping Screw ............................................................. M4x6 ............................... 4

19 ............... PM1200-19 .................. Concave Handle .......................................................... ........................................ 2

20 ............... PM1200-20 .................. RF Transmitter Assembly ............................................. ........................................ 1

20-1 ............ PM1200-2001 .............. RF Transmitter ............................................................. ........................................ 1

20-2 ............ PM1200-2002 .............. Holder .......................................................................... ........................................ 1

20-3 ............ PM1200-2003 .............. Wood Screw ................................................................. M3x12 ............................. 2

21 ............... .................................... Battery (local purchase) ............................................... 9 Volt ............................... 1

22 ............... 6823013 ...................... Black Stripe .................................................................. ........................................ 2

23 ............... PM1200-23 .................. Long Chrome Strip ....................................................... ........................................ 2

24 ............... PM1200-24 .................. Blower Assembly ......................................................... ........................................ 1

24-1 ............ TS-1503071 ................ Socket Head Cap Screw .............................................. M6x30 ............................. 4

24-2 ............ TS-1550041 ................ Flat Washer .................................................................. M6 ................................... 4

24-3 ............ PM1200-2403 .............. Sleeve .......................................................................... ........................................ 4

24-4 ............ PM1200-2404 .............. Rubber Pad .................................................................. ........................................ 4

24-5 ............ TS-1540031 ................ Hex Nut ........................................................................ M5 ................................... 4

24-6 ............ PM1200-2406 .............. Motor Bracket ............................................................... ........................................ 1

24-7 ............ PM1200-2407 .............. Motor ............................................................................ 1/4HP, 115V .................... 1

24-8 ............ TS-1534032 ................ Phillips Pan Head Machine Screw ............................... M6x8 ............................. 12

24-9 ............ PM1200-2409 .............. Air Guide Plate ............................................................. ........................................ 2

24-10 .......... PM1200-2410 .............. Fan Blade ..................................................................... ........................................ 1

24-11 .......... TS-1504021 ................ Socket Head Cap Screw .............................................. M8x12 ............................. 1

24-12 .......... PM1200-2412 .............. Fan Housing ................................................................. ........................................ 1

................... PM1200-HD ................ Hardware Kit (includes index # 5, 6 and 7) .................. ........................................ 1

................... PM1200-ID .................. I.D. Label (not shown) .................................................. ........................................ 1

................... LM000210 ................... Warning Label (not shown) .......................................... ........................................ 1

Items with an asterisk (*) are included in the PM1200-HD Hardware Kit.

Replacement Filters:

Stock No. Description

1791082 Inner Filter, PM1200, 12”x24”x1”

1791083 Disposable Outer Filter, PM1200, 12”x24”x1”

1791084 Charcoal Diffusion Filter, PM1200 (optional)

1791085 Washable Electrostatic Filter, PM1200, 12”x24”x1” (optional)
