This system should be placed on a stable and at surface. Keep the system away

from heat. It shall not be placed in a place that may have inammable gas leakage.

a. Press down the collets and pull out the plugs

of the water inlet and outlet holes in the back

of the system.

b. Connect the water inlet and the three-way ball valve.

Measure the length of the 1/4" pipe you

need to connect the system and the

three-way ball valve, and cut it accordingly

with a pipe cutter. Insert the other end of

the 1/4" pipe which has been connected

with the three-way ball valve into the water

inlet hole in the back of the system. Use a

clip to secure the pipe at the hole.

Note: The inlet water pressure should be within 0.1-0.4 MPa. If the pressure is too

low, a pressure booster should be installed before the system. If the pressure

is too high, a pressure relief valve should be installed before the system.

The pressure relief valve and extra pressure booster need to be purchased

separately.
