Sluit aan op een geschikte stroombron.
Sluit aan op een modem of router met internetverbinding.
Tilslut til en relevant strømkilde.
Tilslut til et modem eller router der har internetadgang.
Koble til en hensiktsmessig strømkilde.
Koble til et modem eller en ruter som har
Internett-tilgang.
Anslut till en lämplig strömkälla.
Anslut till ett modem eller en router som har internetåt-
komst.
Liitä laite yhteensopivaan virtalähteeseen.
Liitä laite modeemiin tai reitittimeen, josta on
Internet-yhteys.
1
2
1
2
1
2
1
2
1
2
Quick Start Guide
ENGLISH | DEUTSCH | FRANÇAIS | ITALIANO
ESPAÑOL | NEDERLANDS | DANSK | NORSK
SVENSKA | SUOMI
Sluit uw computer aan op de Schakelaar met een
Ethernet-kabel. Uw computer dient een IP-adres te
hebben in hetzelfde subnet als de Schakelaar.
Open uw webbrowser en ga naar http://192.168.1.3. Voer
1234 in als wachtwoord. Klik op AANMELDEN.
Tilslut din computer til switchen ved brug af et
Ethernet-kabel. Din computer skal have en IP-adresse i
det samme undernet som switchen.
Start din webbrowser og gå til http://192.168.1.3. Indtast
1234 som adgangskode. Klik på SIGN IN (Log på).
Koble datamaskinen til bryteren ved hjelp av en
Ethernet-kabel. Datamaskinen må ha en IP-adresse i
samme subnett som bryteren.
Åpne nettleseren og gå til http://192.168.1.3. Angi 1234 som
passord. Klikk på LOGG PÅ.
Anslut datorn till switchen med en Ethernet-kabel. Datorn
måste ha en IP-adress i samma subnät som switchen.
Starta din webbläsare och gå till sidan http://192.168.1.3.
Skriv in 1234 som lösenord. Klicka på LOGGA IN.
Liitä tietokone kytkimeen Ethernet-kaapelilla.
Tietokoneen IP-osoitteen on oltava samassa aliverkossa
kytkimen IP-osoitteen kanssa.
Avaa selain ja siirry osoitteeseen https://192.168.1.3. Kirjoita
salasanaksi 1234. Valitse SIGN IN (KIRJAUDU).
3
4
3
4
3
4
3
4
3
4
NL
NO
SE
FI
DK
NL
NO
SE
FI
DK
Norway
+ 47 22 80 61 80
teknisk@zyxel.no
Sweden
+ 46 8 557 760 60
support@zyxel.se
Finland
+ 358 9 4780 8400
teknisk@zyxel.fi
Netherlands
+31 (0)88-00029112
support@zyxel.nl
Denmark
+ 45 30 55 07 00
support@zyxel.dk
Support Information
Copyright © 2017 Zyxel Communications Corp. All Rights Reserved.
EU Importer
Zyxel Communications A/S
Generatorvej 8D, 2860 Søborg, Denmark.
http://www.zyxel.dk
US Importer
Zyxel Communications, Inc
1130 North Miller Street Anaheim, CA 92806-2001
http://www.us.zyxel.com
See the User's Guide at www.zyxel.com
for more information, including customer
support and safety warnings.
5-Port / 8-Port Web Managed
Gigabit Switch
Declaration of Conformity
Safety Warning
QSG
DoC
Power Adapter
Switch
Package Contents
GS1200-5 / GS1200-8
Troubleshooting
I cannot see or access the Login screen in the Web Configurator.
Make sure you are using the correct IP address.
(The default IP address is 192.168.1.3.)
Make sure your computer is in the same subnet as the Switch. If you
haven’t changed the default IP address, your computer IP address should
be in the 192.168.1.4 ~ 168.1.254 range.
Make sure you have entered the Password correctly. If you have changed
the Password and have forgotten it, you’ll have to reset the Switch to its
factory default.
(The default Password is 1234.)
A loop is detected.
A loop may happen in the following example situations:
1. The Switch is connected to another device in a loop state.
2. The Switch is connected to another device with two cables.
Loop Prevention is enabled by default. If a loop happens, the Switch will
block the port in a loop state. If a loop happens on two ports, the Switch
will block the higher-numbered port. For example, if a loop happens on
ports 4 and 5, the Switch will block port 5, and its LED will be off. To restore
a port in a loop state, disconnect it, check the network connections, and
reconnect it.
You can log into the Web Configurator. Go to System in the Web
Configurator to check your port status.
LEDs
PWR/SYS Green
On - Power on
Blinking - Starting up
LINK/ACT
Amber
On
Blinking - Data transmitting
Green
On
Blinking - Data transmitting
- 1000 Mbps
connection ready
- 10/100 Mbps
connection ready
Manage Your Device
2
SIGN IN
Password : 1234
(default)
http://192.168.1.3
Switch IP:
192.168.1.3
PC IP:
192.168.1.4 ~ 192.168.1.254
System Information
Log in
Password 1234
3
4
DC 5V
Power Outlet
Hardware Installation
1
1
2
Back
Front
Modem / Router
