Operation

Climate Line 2000 – 6721831694 (2021/02)

Table 8 Symbols in the display

3.3 Using the remote control

The signal range is 8 m. If objects are in the way or certain fluorescent

lamps are used in the same room this can affect transmission of the

signal.

▶ Point the remote control towards the signal receiver window of the

unit and press the desired key.

The unit emits a beep when it receives a signal.

NOTICE

The remote control may be permanently prevented from working

correctly.

▶ Do not expose the remote control to direct sunlight.

▶ Do not leave the remote control near a heating appliance.

▶ Protect the remote control from moisture and impacts.

3.4 Setting main operating mode

Turn unit on/off

▶Pressthe K key to switch the device on or off:

The device starts in the set operating mode.

Settings can also be made when the device is switched off. The device

saves the settings, and also retains them in the event of a power failure.

Automatic mode

In automatic mode, the device automatically switches between heating

and cooling mode to maintain the desired temperature.

▶ Press the Mode key repeatedly until appears on the display.

▶ Select the required temperature with the . and / keys.

The fan speed cannot be adjusted in automatic mode.

Cooling mode

▶ Press the Mode key repeatedly until appears on the display.

▶ Press the key until the required air speed is reached.

▶ Select the required temperature with the . and / keys.

Fan (Only) Mode

▶ Press the Mode key repeatedly until appears on the display.

▶ Press the key until the required fan speed is reached. AUTO can

be selected to enable automatic control.

The temperature cannot be adjusted or displayed in Fan Mode.

Dehumidification mode

▶ Press the Mode key repeatedly until appears on the display.

▶ Set the required temperature with the . and / keys.

The fan speed cannot be adjusted in dehumidification mode.

Heat mode

▶ Press and hold the Mode key until appears on the display.

▶ Set the required temperature with the . and / keys.

▶ Press the key until the required air speed is reached.

If the outside temperature is very low, the heating capacity of the air

conditioning system may not be sufficient. We recommend connecting

additional heat sources.

3.5 Setback mode

The purpose of this function is to save energy during idle times. After an

hour, the device heats or cools less intensely. To do this, the set

temperature is changed by 1 °C. After two hours the set temperature

changes by a further 1 °C. The new temperature then remains constant.

▶ Press the key to switch the setback mode on or off.

The function is not available in dehumidification mode and Fan Mode.

3.6 Follow me function (Follow Me)

The function activates the remote control at the current location in order

to measure the temperature at 3-minute intervals. The indoor unit is now

controlled with reference to these measurements.

Switch function on or off:

▶ Press the Set key repeatedly until appears.

▶ Confirm with OK key.

The Follow Me function is only available in cooling mode, heating mode

and automatic mode.

3.7 Setting timer

ON and OFF timers can be set to between 0 and 24 hours, in 30-minute

increments for the first 10 hours, then in 1-hour increments. If 0 hours is

set, the timer is cancelled.

Setting the on timer

▶ Press the key until the symbol appears.

▶ Press the . or / key to set the desired time.

The setting is applied shortly afterwards.

Setting the off timer

▶ Press the key until the symbol appears.

▶ Press the . or / key to set the desired time.

The setting is applied shortly afterwards.

Cancelling timer

▶ Press the key to select the corresponding timer.

▶ Set 0.0 hours.

The timer is cancelled after a short time.

3 Value display: shows the set temperature, fan speed

or (when timer is activated) the timer setting as

standard.

Infographic: transmission indicator; lights up when

the remote control sends a signal to the indoor unit.

Infographic: ON/OFF timer active.

Value display: shows the current fan speed. There are

several output stages (bars) and the AUTO setting for

automatic control.

4 Infographic: automatic vertical swing function active.

(up/down).

Infographic: Turbo cool/Turbo heat is active.

Pos. Symbol Explanation
