Pneumatic

Electric

Inner mounted quickly and easily, self located in cen-

ter of the pipe.

Beveling and grooving with high speed, light weight,

good rigdity. Used for the welding preparaon.

Can process facing, flange, convex surface and seal

groove.

Cold cung process will not inuence the quality of

the material of the pipe.

High quality beveling tool, can process dierent grades

of carbon steels, alloy steel, stainless steel and so on.

Can process the U, V and J shape of pipe beveling ac-

cording to the requirements.

Product Description

T-Type Beveling Machine

Electric: Driven by low-energy consumption electric

motor 110V or 220V oponal, 50-60Hz

Pneumac: Drive by pneumac motor. Air working pres-

sure: 0.6-0.8Mpa, Air Consuming ux:650-960L/min

Specications

Technical Parameter

Model No. Size Working Range (ID mm) Wall Thickness (mm) Rated power (KW) Rotating Rate (rpm)

Electric:SDC

Pneumac: TCM

28T 16-28 ≤ 15 0.9 58

80T 28-76 ≤ 15 0.9 55

120T 45-93 ≤ 20 1.4 42

150T 65-159 ≤ 20 1.4 34

350T 150-330 ≤ 20 1.4 16

30TN 12-30 ≤ 15 0.9 58

90TN 25-90 ≤ 15 1.4 42

Beveling Types

other bevel angles or alloy steel, cast steel, please

declare before order
