The Beveling Machine adopts“Y” shape strucon design,

minimal radial space, light weight, easy to carry, safe use.

Inner mounted quickly and easily, self located in cen-

ter of the pipe.

Beveling and grooving with high speed, light weight,

good rigdity. Used for the welding preparaon.

Can process facing, flange, convex surface and seal

groove.

Cold cung process will not inuence the quality of

the material of the pipe.

High quality beveling tool, can process dierent grades

of carbon steels, alloy steel, stainless steel and so on.

Can process the U, V and J shape of pipe beveling ac-

cording to the requirements.

Product Description

Y-Type Beveling Machine

Electric: Driven by low-energy consumption electric

motor 110V or 220V oponal, 50-60Hz

Pneumatic: Driven by pneumatic motor. Air working

pressure: 0.6-0.8Mpa, Air Consuming ux:650-960L/min

Specications

other bevel angles or alloy steel, cast steel, please de-

clare before order

Beveling Types

Technical Parameter

Model No. Size Capacity (ID mm) Wall thickness(mm) Rated Power (KW) Rotating Speed(rpm)

Electric: ISY

Pneumac: TCM

150 65-159 ≤ 15 1.4 34

250 80-240 ≤ 15 1.4 16

351 150-330 ≤ 15 1.4 14

630 300-600 ≤ 15 1.4 10

850 600-820 ≤ 15 2.0 9

Model No. Size Capacity (ID mm) Wall thickness(mm) Rated Power (KW) Rotating Speed(rpm)

Electric: ISY

Pneumac: TCM

250-II 80-240 ≤ 75 1.4 16

351-II 150-330 ≤ 75 1.4 14

630-II 300-600 ≤ 75 1.4 10

850-II 600-820 ≤ 75 2.0 9
