LG PQNFG14B0 [2/99] Table of contents

2 CNU

CNU

TABLE OF CONTENTS

■ Cautions for safety .................................................................................................3

■ Part Description ......................................................................................................6

Parts of a CNU..........................................................................................................6

CNU connection........................................................................................................7

■ Wiring Diagram ......................................................................................................8

Multi V SUPER(PLUS) & MPS PRODUCT...............................................................8

Connection................................................................................................................9

■ Network Interface Connection.............................................................................11

Dip Switch Configuration.........................................................................................11

■ CNU setup method................................................................................................12

Connect with the PC ...............................................................................................12

Set the PC environment for CNU IP setting............................................................13

CNU Setup Configuration .......................................................................................18

■ CNU Normal operation condition confirmation .................................................19

Hardware operation condition confirmation ............................................................19

LAN communication condition confirmation ...........................................................19

485 Communication condition confirmation............................................................19
