Connecting the cables

Connectthecablesasshown:

1. Power cord

2.Audio-incable(formodels

with speakers)

4.

DVIsignalcable(forsome

models)

VGAsignal

•

To connect the power cord

:connectoneendofthepowercordsecurelyto

themonitor’sACinputport,andtheotherendtoapoweroutlet.

•

To connect the VGA/DVI cable

:

 a. PlugtheVGA/DVIconnectortotheLCDmonitor’sVGA/DVIport.

b. ConnecttheotherendoftheVGA/DVIcabletoyourcomputer’sVGA/

 DVIport.

c. TightenthetwoscrewstosecuretheVGA/DVIconnector.

•

To connect the audio cable (For those models with speakers)

:connectone

endoftheaudiocabletothemonitor’sAudio-inport,andtheotherendtothe

computer'saudio-outport.

WhenboththeVGAandtheDVIcablesareconnected,youcanchooseeither

VGAmodeorDVImodefromtheInputSelectitemoftheOSDfunctions(for

some models).

Rear view

Stereo speakers (for

some models)

3 4
