Body and Hand Position (Fig. M1–M4)
WARNING: To reduce the risk of serious personal injury, ALWAYS use proper hand
position asshown.
WARNING: To reduce the risk of serious personal injury, ALWAYS hold securely in
anticipation of a suddenreaction.
Proper positioning of your body and hands when operating the mitre saw will make cutting
easier, more accurate and safer. Never place hands near cutting area. Place hands no closer
OPERATION
Instructions for Use
WARNING: Always observe the safety instructions and applicableregulations.
WARNING: To reduce the risk of serious personal injury, turn tool off and
disconnect tool from power source before making any adjustments or removing/
installing attachments or accessories. An accidental start-up can causeinjury.
Changing or Installing a New Saw Blade (Fig.D–F)
WARNING: To reduce the risk of serious personal injury, turn off the tool and
disconnect it from the power source before attempting to move it, change
accessories or make anyadjustments.
WARNING: When mounting the saw blade, wear protective gloves. Danger of
injury when touching the sawblade.
CAUTION:
• Never depress the spindle lock button while the blade is under power orcoasting.
• Do not cut ferrous metal (containing iron or steel) or masonry or fiber cement product
with this mitresaw.
Removing the Blade
1. Unplug thesaw.
2. Raise the arm to the upper position and raise the lower guard
4
as far aspossible.
3. Loosen, but do not remove guard bracket screw
21
until the bracket can be raised far
enough to access the blade screw. Lower guard will remain raised due to the position of
the guard bracketscrew.
4. Depress the spindle lock button
22
while carefully rotating the saw blade by hand until
the lockengages.
5. Keeping the button depressed, use the other hand and the 6 mm hex wrench
16
provided to loosen the blade screw
24
. (Turn clockwise, left-hand threads.)
6. Remove the blade screw
24
, outer blade clamp
25
, and blade
26
. The inner blade
clamp
27
, and if used, the 25.4 mm blade adapter
37
, may be left on thespindle.
nOTE: For blades with a blade hole of 15.88 mm, the 25.4 mm blade adapter is notused.
Installing a Blade
1. Unplug thesaw.
2. With the arm raised, the lower guard held open and the guard bracket, place the
blade
26
on the spindle against the inner blade clamp
27
with the teeth at the bottom
of the blade pointing toward the back of thesaw.
3. Assemble the outer blade clamp
25
onto thespindle.
4. Install the blade screw
24
and, engaging the spindle lock, tighten the screw firmly with
the 6 mm hex wrench provided. (Turn counterclockwise, left-hand threads.)
5. Return the guard bracket to its original position and firmly tighten the guard bracket
screw
21
to hold bracket inplace.
WARNING:
• The guard bracket must be returned to its original position and the screw
tightened before activating thesaw.
• Failure to do so may allow the guard to contact the spinning saw blade
resulting in damage to the saw and severe personalinjury.
Mitre Scale Adjustment (Fig.A, G)
Place a square against the saw’s fence and blade. (Do not touch the tips of the blade teeth
with the square. To do so will cause an inaccurate measurement.) Unlock mitre lock knob
5
and swing the mitre arm until the mitre detent locks it at the 0˚ mitre position. Do not lock
mitre lock knob. If the saw blade is not exactly perpendicular to the base fence
18
, loosen
the three mitre scale screws
8
that hold the mitre scale
7
to the base and move the scale/
mitre arm assembly left or right until the blade is perpendicular to the fence, as measured with
the square. Retighten the three screws. Pay no attention to the reading of the mitre pointer at
thispoint.
Mitre Pointer Adjustment (Fig.A, H)
Unlock mitre lock knob
5
and squeeze the mitre detent latch
6
to move the mitre arm to
the zero position. Unlock the mitre lock knob to allow the mitre detent to snap into place as
you rotate the mitre arm toward zero. Observe the pointer
23
and mitre scale
7
through the
viewing opening shown in FigureH. If the pointer does not indicate exactly zero, loosen the
pointer screw, adjust the pointer to 0˚ andretighten.
Bevel Square to Table (Fig. I, J)
To align the blade square to the rotary table, lock the arm in the down position. Place a square
against the blade taking care to not have the square on top of a tooth. Loosen the bevel lock
knob
11
so that you can move the bevel arm. Move the bevel arm as necessary so that the
blade is at 0° bevel to the table. If the bevel arm needs adjustment, locate the right side bevel
stop as shown in FigureJ, and adjust the stop screw
28
asnecessary.
Bevel Pointer (Fig.J)
If the bevel pointer
30
does not indicate zero, loosen the screw
31
that holds it in place and
move the pointer asnecessary.
sUggEsTiOn: For accuracy, set the top edge so that it aligns withzero.
Bevel Stop (Fig.A, J)
To set the 45° bevel stop, first loosen the left side fence lock knob
14
and slide the sliding
fence
10
as far as it will go to the left. Move the arm to the left until it stops on the left
side bevel stop screw
29
. If the bevel pointer does not indicate exactly 45°, turn the screw
ASSEMBLY AND ADJUSTMENTS
WARNING: To reduce the risk of serious personal injury, turn tool off and
disconnect tool from power source before making any adjustments or removing/
installing attachments or accessories. An accidental start-up can causeinjury.
FigureA. To transport the saw, lower the arm and tighten the head lock knob
17
shown in
FigureC.
downwards. Move the arm to the left and tighten the bevel lock knob
11
firmly when the
bevel pointer indicates exactly 45°. Adjust the left side bevel stop screw
29
upwards until it
firmly touches the bevelstop.
To achieve 3° right bevel or 48° left bevel, the stop screws must be adjusted to allow the arm
to move to the desired location. The bevel stops will need readjustment to the zero and 45°
positions after cuts aremade.
Fence Adjustment (Fig.K)
WARNING: To reduce the risk of serious personal injury, turn off the tool and
disconnect it from the power source before attempting to move it, change
accessories or make anyadjustments.
To bevel UP TO 48° left, the left side of the fence can be adjusted to the left to provide
clearance. To adjust the fence, loosen the fence lock knob
14
and slide the fence to the left.
Make a dry run with the saw turned off and check for clearance. Adjust the fence to be as close
to the blade as practical to provide maximum workpiece support, without interfering with
arm up and down movement. Tighten the fence clamping knob securely. When the bevel
operations are complete, don’t forget to relocate the fence to theright.
Guard Actuation and Visibility (Fig.L)
CAUTION: Pinch Hazard. To reduce the risk of injury, keep thumb underneath the handle
when pulling the handle down. The lower guard will move up as the handle is pulled
down which could causepinching.
The blade guard on your saw has been designed to automatically raise when the arm is
brought down and to lower over the blade when the arm israised.
The guard can be raised by hand when installing or removing saw blades or for inspection of
the saw. NEVER RAISE THE BLADE GUARD MANUALLY UNLESS THE SAW IS TURNEDOFF.
nOTE: Certain special cuts will require that you manually raise the guard. Refer to Cutting
Large Material under SpecialCuts.
The front section of the guard is louvered for visibility while cutting. Although the louvers
dramatically reduce flying debris, there are openings in the guard and safety glasses should be
worn at all times when viewing through thelouvers.
Automatic Electric Brake
Your saw is equipped with an automatic electric blade brake which stops the saw blade within
5seconds of trigger release. This is notadjustable.
On occasion, there may be a delay after trigger release to brake engagement. On rare
occasions, the brake may not engage at all and the blade will coast to astop.
If a delay or “skipping” occurs, turn the saw on and off 4 or 5 times. If the condition persists,
have the tool serviced by an authorised
DeWALT
servicecentre.
Always be sure the blade has stopped before removing it from the kerf plate. The brake
is not a substitute for guards or for ensuring your own safety by giving the saw your
completeattention.
Controls
Your compound mitre saw has several main controls, which will be discussed briefly here. For
more information on these controls, see the respective sections later in themanual.
Mitre Control (Fig.A)
The mitre lock knob
5
and mitre detent latch
6
allow you to mitre your saw 50° left and right.
To mitre the saw, unlock mitre lock knob
5
by rotating the knob counterclockwise, squeeze
the mitre detent latch
6
and set the mitre angle desired on the mitre scale. Lock mitre lock
knob by rotating clockwise until tight. Override the mitre detent latch by unlocking the mitre
lock knob and pushing the mitre detent override
20
downward. To exit the override, push the
mitre detent override switchupward.
Bevel Lock (Fig.J)
The bevel lock knob
11
allows you to bevel the saw 48° left and 3° to the right. To loosen the
handle and adjust the bevel setting, turn the handle counter clock wise, the saw head bevels
easily to the left. To tighten, turn the handle clockwise. Bevel degree markings are on the
bottom front of the saw arm (Fig.H).
Head Downlock Pin (Fig.A)
To lock the saw head in the down position, push the head down, rotate head lock knob
17
90° and the spring loaded pin will lock in and release the saw head. This will hold the saw head
safely down for moving the saw from place to place. To release, pull out the head lock knob
and rotate90°.
