ENGLISH

Optional Accessories



WARNING: Since accessories, other than those offered by

DeWALT

, have not been tested

with this product, use of such accessories with this tool could be hazardous. To reduce the

risk of injury, only

DeWALT

recommended accessories should be used with thisproduct.

Consult your dealer for further information on the appropriateaccessories.

Cleaning



WARNING: Blow dirt and dust out of the main housing with dry air as often as dirt is seen

collecting in and around the air vents. Wear approved eye protection and approved dust

mask when performing thisprocedure.



WARNING: Never use solvents or other harsh chemicals for cleaning the non-metallic

parts of the tool. These chemicals may weaken the materials used in these parts. Use a

cloth dampened only with water and mild soap. Never let any liquid get inside the tool;

never immerse any part of the tool into aliquid.

Lubrication

Your power tool requires no additionallubrication.

DO NOT use lubricants or cleaners (particularly spray or aerosol) in the vicinity of the plastic

guard. The polycarbonate material used in the guard is subject to attack by certainchemicals.

1. All bearings are sealed. They are lubricated for life and need no furthermaintenance.

2. Periodically clean all dust and wood chips from around AND UNDER the base and the

rotary table. Even though slots are provided to allow debris to pass through, some dust

willaccumulate.

3. The brushes are designed to give you several years of use. To replace the brushes, return

the tool to the nearest service centre for repair. A list of service centre locations is packed

with yourtool.

MAINTENANCE

Your power tool has been designed to operate over a long period of time with a minimum

of maintenance. Continuous satisfactory operation depends upon proper tool care and

regularcleaning.



WARNING: To reduce the risk of serious personal injury, turn tool off and

disconnect tool from power source before making any adjustments or removing/

installing attachments or accessories. An accidental start-up can causeinjury.

For Cutting Crown Molding Laying Flat and Using the Compound

Features (Fig. T)

1. Move the sliding fence

10

out of the path of the blade before attempting any of the

followingcuts.

2. Molding laying with broad back surface down flat on saw table

36

(Fig.T).

BEVEL SETTING TYPE OF CUT

33.9°

LEFT SIDE, INSIDE CORNER

1. Top of molding against fence

2. Mitre table set right 31.6°

3. Save left end of cut

33.9°

RIGHT SIDE, INSIDE CORNER

1. Bottom of molding against fence

2. Mitre table set left 31.6°

3. Save left end of cut

33.9°

LEFT SIDE, OUTSIDE CORNER

1. Bottom of molding against fence

2. Mitre table set left 31.6°

3. Save right end of cut

33.9°

RIGHT SIDE, OUTSIDE CORNER

1. Top of molding against fence

2. Mitre table set right 31.6°

3. Save right end of cut

When setting bevel and mitre angles for all compound mitres, remember that:

The angles presented for crown moldings are very precise and difficult to set exactly. Since

they can easily shift slightly and very few rooms have exactly square corners, all settings should

be tested on scrapmolding.

PRETESTING WITH SCRAP MATERIAL IS EXTREME LY IMPORTANT!

Alternative Method for Cutting Crown Molding (Fig. U)

Place the molding on the table at an angle between the sliding fence

10

and the saw

table

36

, as shown in FigureU. Use of the crown molding fence accessory (DW7084) is highly

recommended because of its degree of accuracy and convenience. The crown molding fence

accessory is available at extra cost from your localdealer.

The advantage to cutting crown molding using this method is that no bevel cut is required.

Minute changes in the mitre angle can be made without affecting the bevel angle. This way,

when corners other than 90° are encountered, the saw can be quickly and easily adjusted for

them. Use the crown molding fence accessory (DW7084) to maintain the angle at which the

molding will be on thewall.

Instructions for Cutting Crown Molding Angled Between the Fence and

Base of the Saw for All Cuts (Fig. U)

1. Angle the molding so the bottom of the molding (part which goes against the wall when

installed) is against the fence and the top of the molding is resting on the base of the saw,

as shown in FigureU.

2. The angled “flats” on the back of the molding must rest squarely on the fence and base of

thesaw.

Inside corner Outside corner

Left side

1. Mitre right 45°

2. Save right side of cut

1. Mitre left 45°

2. Save right side of cut

Right side

1. Mitre left 45°

2. Save left side of cut

1. Mitre right 45°

2. Save left side of cut

Special Cuts

NEVER MAKE ANY CUT UNLESS THE MATERIAL IS SECURED ON THE TABLE AND AGAINST

THEFENCE.

Aluminum Cutting (Fig, A, V, W)

ALWAYS USE THE APPROPRIATE SAW BLADE MADE ESPECIALLY FOR CUTTING ALUMINUM.

These are available at your local

DeWALT

retailer or

DeWALT

service centre. Certain workpieces,

due to their size, shape or surface finish, may require the use of a clamp or fixture to prevent

movement during the cut. Position the material so that you will be cutting the thinnest cross

section, as shown in FigureV. Figure W illustrates the wrong way to cut these extrusions. Use

a stick wax cutting lubricant when cutting aluminum. Apply the stick wax directly to the saw

blade

26

before cutting. Never apply stick wax to a movingblade.

The wax, available at most hardware stores and industrial mill supply houses, provides proper

lubrication and keeps chips from adhering to theblade.

Be sure to properly secure workpiece. Refer to Saw Blades under Optional Accessories for

correct sawblade.

Bowed Material (Fig. X, Y)

When cutting bowed material always position it as shown in Figure X and never like that

shown in Figure Y. Positioning the material incorrectly will cause it to pinch the blade near the

completion of thecut.

Cutting Plastic Pipe or Other Round Material

Plastic pipe can be easily cut with your saw. It should be cut just like wood and CLAMPED

OR HELD FIRMLY TO THE FENCE TO KEEP IT FROM ROLLING. This is extremely important

when making anglecuts.

The following accessories, designed for your saw, may be helpful. In some cases, other locally

obtained work supports, length stops, clamps, etc., may be more appropriate. Use care in

selecting and usingaccessories.

Adjustable Length Stop: DW7051

Requires the use of one work support. It is used to make repetitive cuts of the same length

from 0 to 107cm.

Clamp: DW7082

Used for firmly clamping workpiece to the saw fence for precisioncutting.

Dust Bag: DW7053

Included with some models

Equipped with a zipper for easy emptying, the dust bag will capture the majority of the

sawdustproduced.

Crown Molding Fence: DW7084

Used for precision cutting of crownmolding.

Mitre Saw Stands: DWX723, DE7260, DE7033

Provides stable and accurate work platform for mitresaws.

Saw Blades

ALWAYS USE 254mm SAW BLADES WITH 16 mm ARBOUR HOLES. SPEED RATING MUST BE

AT LEAST 5500 RPM. Never use a smaller diameter blade. It will not be guarded properly. Use

crosscut blades only! Do not use blades designed for ripping, combination blades or blades

with hook angles in excess of 7degrees.

BLADE DESCRIPTIONS

APPLICATION DIAMETER TEETH

Construction Saw Blades (thin kerf with anti-stick rim)

General purpose 254 mm 40

Fine crosscuts 254 mm 60

Woodworking Saw Blades (provide smooth, clean cuts)

Fine crosscuts 254 mm 80

Non-ferrous metals 254 mm 80

NOTE: For cutting non-ferrous metals, use only saw blades with TCG teeth designed for this purpose.

Cutting Large Material (Fig. L)

Occasionally you will encounter a piece of wood a little too large to fit beneath the blade

guard. A little extra height can be gained by rolling the guard up out of the way, as shown in

FigureL. Avoid doing this as much as possible, but if need be, the saw will operate properly

and make the bigger cut. NEVER TIE, TAPE, OR OTHERWISE HOLD THE GUARD OPEN WHEN

OPERATING THISSAW.
