20 | English
Grass trimmer EasyGrassCut 23 EasyGrassCut 26
No-load speed min
-1
12500 12500
Cutting line diameter mm 1.6 1.6
Cutting diameter cm 23 26
Cutting spool capacity m 4.0 4.0
Weight according to EPTA‑Proced-
ure 01:2014
kg 2.0 2.0
Protection class
/ II / II
Serial number see type plate on garden tools
The specifications apply to a rated voltage [U] of 230 V. These specifications may vary at different voltages and in country-specific models.
Noise/Vibration Information
3 600 HC1 H.. 3 600 HC1 J..
Noise emission values determined according to EN 50636-2-91.
Typically the A-weighted noise levels of the product are:
Sound pressure level dB(A)
78 80
Uncertainty K dB
= 2.5 = 2.5
Sound power level dB(A)
90 91
Uncertainty K dB
= 2.0 = 1.0
Vibration total values ah (triax vector sum) and uncertainty K determined according to EN 50636-2-91
Vibration emission value a
h
m/s
2
< 2.5 < 2.5
Uncertainty K m/s
2
= 1.5 = 1.5
Mounting and Operation
Action Figure Page
Product features
A
325
Delivery scope
B
326
Removing the transport safety
C
326
Connecting the shaft
D
327
Adjusting the Handle
E
327
Mounting the protection guard
F
328
Connecting the extension cable
Switching On and Off
G
329
Removing the line spool
H
329
Winding line on spool
I
330
Mounting the line spool
J
330
Line feeding
K
331
Maintenance, Cleaning and Stor-
age
L
331
Accessories
M
332
Assembly
u Caution: Switch the garden tool off and pull the mains
plug before performing any maintenance.
Connect shaft (see figures C and D)
Note: A connected shaft can no longer be dismounted.
Remove the transport safety (7).
Connect the individual parts of the shaft until they can be
heard to engage.
Mounting and adjusting the handle (see figure E)
The handle (1) can be set to different positions. To change
the adjustment, press buttons (5) and move the handle to
the desired position. Release the buttons (5) again so that
the handle can engage.
Mounting the protection guard (see figure F)
Before mounting the protective guard, pull the plant-protec-
tion frame from the delivery position to the storage position.
Position the protection guard (6) on the trimmer head and
fasten it with the provided screw.
Do not disassemble guard once connected.
Then, pull the plant-protection frame to the working posi-
tion.
Operation
u Pay attention to the mains voltage. The voltage of the
power source must match the voltage specified on the
rating plate of the machine.
F 016 L94 303 | (22.07.2021) Bosch Power Tools
