Product Information

Manufacturer LEO

Address China,Zhejiang,Wenling

XST65-160/110

Contact

Date

Project Name

Client Name LEO Sibir LLC

Client Addr. Novosibirsk

Item NO

Contacts

Contact

Part NO. 50010452

Product Picture Note

Water supply: Water filtration and transportation, the main pipeline

pressurization; Pressurization for high-rise buildings, hotels, etc.

Industry: Flushing and cleaning system, boiler feed water, cooling water

circulation, water treatment system, equipment supporting system.

water treatment: Ultrafiltration system, reverse osmosis system,

distillation system, separator,swimming pool.

Other: Air conditioning system; heating system; agricultural irrigation,fire

fighting system

Nameplate parameters

flow 74 m³/h

head 33 m

Efficiency 72 %

speed 2900 rpm

number of stages 1

Technical

Flow range (m³/h) 7.4-120m3/h

Curve tolerance ISO 9906 Annex A

Maximum lift (m) 36m

Maximum Altitude 1000m

Material

Impeller HT200/06Cr19Ni10

Pump inlet HT200

Pump shaft 45/06Cr19Ni10

Fan cover

O-ring NBR

Rear end cover

Connector HT200

Fan

Cover box

Supporting foot

Guard plate 06Cr19Ni10

Working conditions

Medium temperature (°C) -10°C+85°C

Max. ambient temperature (°C) +40°C

Pumped medium

Liquid without solid particles and long fiberslow viscositynon-combustiblenon-corrosion liquid or other

Critical cavitation margin(m) 3.5m

Working pressure 12bar

Installation

Structure Type Standard motor ( sleeve shaft)

Connection method Flange connection / thread-connection

Inlet diameter (mm) DN80

Outlet diameter (mm) DN65

Motor

Motor phase Three phase

-1-
