Recording a video

Click the corresponding icon on the toolbar or select Video from the Capture menu.

The camcorder icon on the toolbar will change once you start recording. To stop recording

you can either click the corresponding icon on the toolbar again or select Stop capturing

from the Capture menu.

Note: recommended video resolution is 640x480.

Preview

Left-click the thumbnail of the image you wish to edit and it will open in the main window

of the application. The image resolution will be displayed in the bottom left corner of the

screen. Double-clicking a thumbnail will open the image in a separate window.

Saving images

To save an image, right-click the thumbnail of the desired image and select Save from the

drop-down menu.Images may be saved in .jpeg and .bmp formats. When saving images in

.jpeg format, clicking Advanced allows you to view and edit additional options.

Deleting images

To delete an image, right-click the thumbnail of the desired image and select Delete from

the drop-down menu.When viewing images in a separate window, you can click the

corresponding icon on the toolbar to delete the image.

Copying images

To copy an image, right-click the thumbnail of the desired image and select Copy

from the drop-down menu.

Calibration and measurements

Place a ruler on the stage, focus your view and aimage. Take note of the current

magnification by looking at the calibration scale on the microscope body. Double-click the

image thumbnail to open it in a separate window. Enter the magnification value into the

corresponding field in the upper right corner of the preview window. Upon calibrating the

microscope, you will be able to measure various parameters of observed specimens. All

the buttons on the toolbar of the preview window are described below.

Line

Press and hold the left mouse button to start drawing a line. Release the left mouse button

to complete the line.

Free-form line

Press and hold the left mouse button and draw a line. Release the left mouse button

to complete the segment. You can continue adding more segments to the free-form line.

Press this button to create a text box on the image

Press this button to edit font parameters

These buttons allow you to draw something on the image

Press this button to choose the line color

Press this button to choose the line thickness

Press this button to choose the line style

Press this button to undo the last action

Note:

1. Magnification range of Levenhuk DTX 50 is 20x–400x, and 20x–230x for Levenhuk DTX 30.

Do not use magnification values that exceed this range.

2. The application calculates values based on the magnification you have entered.

The results may not be precise.

Radius

Draw a straight line on the image. The application will automatically calculate the radius,

as well as circumference and area of the corresponding circle.

Diameter

Draw a straight line on the image. The application will automatically calculate

the diameter, as well as circumference and area of the corresponding circle.

Angle

Press and hold the left mouse button to draw a line on the image. Release the left mouse

button and draw another line. The application will automatically calculate value

of the resulting angle.

Measurement units

From the drop-down menu on the toolbar you can select measurement units

for calculations (pixels, inches, kilometers, meters, centimeters, millimeters, microns).
