Product Information

Manufacturer LEO

Address China,Zhejiang,Wenling

LPP80-20-5.5/2

Contact

Date

Project Name

Client Name LEO Sibir LLC

Client Addr. Novosibirsk

Item NO

Contacts

Contact

Part NO. LPP80-20-5.5/2

Product Picture Note

:

CFD

Nameplate parameters

flow 70 m³/h

head 20 m

speed 2900 rpm

number of stages 1

Technical

Curve tolerance IS09906 AnnexA

Maximum lift (m) 25

Minimum usage flow (m³/ h) 7

Maximum use flow (m³/ h) 90

Material

Impeller HT200

Pump inlet HT200

Pump shaft AISI304

Mechanical seal SiC/C

O-ring NBR

Working conditions

Max. ambient temperature (°C) 40

Max. liquid temperature (°C) 90

Pumped medium

Working pressure 16bar

Installation

Inlet & Outlet Diameter DN80

Connection standard DIN

Motor

Motor phase Three phase

Protection class IP55

Motor poles 2

Insulation class F

Motor power (KW) 5.5KW

Frequency 50

Rated voltage (V) 380

Rated current (A) 10.6456194876593

Efficiency class IE3

Power factor 0.88

-1-
