Omperator's anual

www.fubag.ru

--2

2. Description

The rinder is a manual pneumatic tool used for weld dressing, steel and iron casting,

metalware as well as for metal-roll cutting.

angel g

Caution:

If revealing any faults immediately discontinue the operation.

When connecting the pneumatic tool to the compressor hose always block the air escape

cock.

Always follow the safety rules when using the compressed air.

3s. Technical pecifications

The manufacturer reserves himself the right to make the manual's content or function

change without any preliminary notification of the users.

tools

4. Connection and operation

It is necessary to re-activate the tool before the operation start. To re-activate the tool pour the pure

paraffin through the inlet connecting pipe when the trigger is open, then blow the tool through with

the dry compressed air. Repeat it 2 or 3 times.

The system of the compressed air lead-in to the tool is in the below diagram.

Before the first putting the tool into operation it is necessary to pour in 5-10 ml of the machine oil as

per specification SAE#10 or its analog through the connecting pipe of the compressed air lead-in.

Blow the air hose through. Connect it to the tool, press the starting lever and operate the tool at no

load running within 2-3 minutes.After it release the starting lever.

If the lubricator is not used during the operation it is necessary to pour 5-10 ml of the machine oil as

per specification SAE#10 or its analogue into the inlet connecting pipe of the tool every operating

hour.

MODEL 100113 100127

Grinding disk diameter acceptable, mm 100 125

No load spindle rotation speed, rpm 10000 10000

Inlet diameter, inch

Total air consumption, l/min 740 740

Average air consumption at work cycle min , l/min 186 186

Operating pressure, bar 6,3 6,3

Weight, kg 1,76 2,1

Air conductive hose diameter recommended, mm 6х8 6х8
