Makita LXT DGA519Z Чертеж деталей онлайн [2/3] 853618

Model No.DGA519 125MM CORDLESS ANGLE GRINDER

Item Parts No. Description I/C Qty New/Old Opt. 1 Opt. 2 Note

001 266326-2 TAPPING SCREW 4X18 5

002 183H86-8 MOTOR HOUSING SET 1

󳢢󳢢󳢢󳢢C10 263005-3 RUBBER PIN 6 2

󳢢󳢢󳢢󳢢D10 INC. 39

003 455450-8 DUST COVER R 1

004 632E12-1 SWITCH UNIT 1

005 650734-1 SWITCH TG73BDS-2 1

006 234357-9 COMPRESSION SPRING 11 1

007 142901-7 INDICATOR PANEL COMPLETE 1

008 142976-6 SWITCH LEVER COMPLETE 1

009 629304-7 STATOR COMPLETE 1

010 210169-4 BALL BEARING 607LLB 1

011 510440-9 ROTOR ASS'Y 1

󳢢󳢢󳢢󳢢D10 INC. 10

012 135930-7

GEAR HOUSING COVER

ASSEMBLY

󳢢󳢢󳢢󳢢D10 INC. 13

013 213445-5 O-RING 26 1

014 210042-8 BALL BEARING 629LLB 1

015 226950-3 SPIRAL BEVEL GEAR 10 1

016 252186-8 HEX. NUT M6 1

017 140N76-0 GEAR HOUSING COMPLETE 1

018 459967-3 LEVER 1

019 961017-7 STOP RING E-3 1

020 232576-1 TORSION SPRING 5 1

021 256935-5 HEADED PIN 4 1

022 266361-0 TAPPING SCREW 4X30 4

023 327460-4 SHAFT 1

024 961104-2 RETAINING RING S-24 1

025 226951-1 SPIRAL BEVEL GEAR 37 1

026 962201-7 RETAINING RING (INT) R-42 1

027 210208-0 BALL BEARING 6905DDW 1

028 213622-9 O RING 45 1

029 136199-6 BEARING BOX ASS'Y 1

󳢢󳢢󳢢󳢢D10 INC. 28

030 327322-6 SLEEVE 4 2

031 232490-1 COMPRESSION SPRING 4 1

032 347615-5 LEVER 1

033 911159-7 PAN HEAD SCREW M4X30 2

034 911138-5 P.H.SCREW M4X20 WITH WR 2

035 232577-9 SCROW WAVE SPRING 49 1

036 347618-9 WHEEL COVER 125 1

037 327459-9 RING 25 1

Please order the parts with part number. Print Date 23/9/2020
