6 EN

ozone meter OZ-ONE

Scope of delivery

• 1x Device OZ-ONE

• 1x Calibration certificate

• 4x AAAbatteries

• 1x Quick guide

• 1x Transport bag

Transport and storage

Note

If you store or transport the device improperly, the

device may be damaged.

Note the information regarding transport and storage of

the device.

Transport

For transporting the device, use the bag included in the scope of

delivery in order to protect the device from external influences.

Storage

When the device is not being used, observe the following

storage conditions:

• dry and protected from frost and heat

• protected from dust and direct sunlight

• with a cover to protect it from invasive dust if necessary

• Store the device in the resealable zip bag it has been

supplied in.

• The storage temperature is the same as the range given in

the Technical data chapter.

• Remove the batteries from the device.

Operation

Inserting the batteries

Note

Make sure that the surface of the device is dry and the

device is switched off.

1. Open the battery compartment by sliding open the

cover(12) with your fingers.

2. Remove the battery compartment cover.

3. Insert the batteries (4batteries of typeAAA) into the

battery compartment with correct polarity.

4. Slide the cover back onto the battery compartment.

Switch-on and ozone level measurements

Note

Never expose the sensor to hard shocks. Do not shake

the sensor, e.g. to ventilate the sensor chamber after

an oversaturation, since the reaction electrolyte in the

sensor can be irreparably damaged.

Note

Do not blow into the sensor ball and do not actively

warm it in your hand, e.g. by encompassing it, because

temperature, changing humidity as well as air currents

can influence and falsify the measurement result.

Moreover, if the humidity level has been rapidly

increased all of a sudden, interruptions of the sensor

output can occur ("rEg", see chapter Errors and faults).

Note

Note that moving from a cold area to a warm area can

lead to condensation forming on the device's circuit

board. This physical and unavoidable effect can falsify

the measurement. In this case, the display shows

either no measured values or they are incorrect. Wait a

few minutes until the device has become adjusted to

the changed conditions before carrying out a

measurement.

1. Briefly press the Power button(9).

ð The display will be activated and the device will be in a

warm-up phase for about three minutes.

ð At the end of that phase the device is ready for

operation and can be used for measurements.

ð On the measurement value display the device indicates

the ozone concentration(16) as well as the relative

humidityand ambient temperature(19).

Info

If no ozone concentration is detected in the current

measuring range, the measuring device indicates

"0.00" on the measurement value display(16).
