EN 9

ozone meter OZ-ONE

7. Press the HOLD button(10) to increase the value deviation.

Press the Lamp button(4) to reduce the value. You can set

a value deviation of up to ±9.9%RH.

8. Press the SETbutton(7) to save the values.

ð "SAVE" will appear on the display(11) for approx.

2seconds.

9. Press and hold the Power button(9) for approx. 3seconds.

ð The device will be switched off. The values are

adjusted.

Ozone zero adjustment

To calibrate the device, an ozone zero adjustment can be made

in an ozone-free environment. To do so, please proceed as

follows:

1. Simultaneously press and hold the UNIT(3) button and the

SET(7) button.

ð "CAL" will appear on the display(11).

2. Simultaneously press the UNIT(3) button and SET(7)

button again.

ð The calibration is started. The device counts backwards

from 120.

ð Upon successful calibration, "End" appears on the

display(11).

Info

Ensure to carry out the calibration in surroundings that

are free of other gases the sensor reacts to, e.g.

nitrogen dioxide. For more detailed information about

cross-sensitivities please refer to the chapter Errors

and faults.

De-/Activating the alarm function for the ozone limit value

Once the ozone limit value has been configured, the alarm

function can be activated or deactivated by hand.

Please proceed as follows to configure the alarm function at the

device:

1. Press the Power button(9) for approx. 1s.

ð The activated alarm indication(20) will be displayed and

the alarm function is activated.

2. Press the Power button(9) again for approx. 1s to

deactivate the alarm function.

ð The activated alarm indication(20) will no longer be

displayed and the alarm function is deactivated.

Automatic switch-off

In default setting, the automatic switch-off function is activated.

The device switches off when not in use for 15 minutes.

To deactivate automatic switch-off at the device, please

proceed as follows:

1. Switch the device off by pressing the Power button(9) and

holding it for approx.3s.

2. Simultaneously press the Power button(9) and the HOLD

button(10) until the message "n" is displayed.

ð Automatic switch-off is permanently deactivated.

Info

If you switch off the device manually, the automatic

switch-off setting is reset, i.e. automatic switch-off is

activated again when the device is switched back on.

Switch-off

If automatic switch-off is activated, the device switches off after

15minutes of non-use.

1. Press and hold the Power button(9) for approx. 3seconds.

ð The device will be switched off.
