ENGLISH

FAN MW-3546 BK

The fan is intended for artificial ventilation

of the room

FAN DESCRIPTION

1. Front safety grid

2. Plastic blade clamp

3. Clamp ring

4. Fastening screw

5. Blades

6. Rear grid plastic fastening nut

7. Rear grid

8. Fan carrying handle

9. Motor axis

10. Control panel

11. Oscillation On/Off button

12. Motor unit

13. Motor unit clamp

14. Telescopic bar

15. Telescopic bar clamp

16. Decorative panel

17. Supports

18. Fastening screws

SAFETY MEASURES

Before using the electrical appliance, read

this instruction manual carefully, and keep it

for further reference.

Use the unit for intended purposes only, as

specified in this manual. Mishandling the

unit can lead to its breakage and cause harm

to the user or damage to his/her property.

• Before switching the unit on for the first

time, make sure that your home mains

voltage corresponds to unit operating

voltage.

• Before using the unit, examine the power

cord closely and make sure that it is not

damaged. If you find that the power cord

is damaged, do not use the unit.

• Do not use the fan outdoors.

• Place the unit on a flat, dry and steady

surface away from sources of heat or

open flame.

• Do not use the unit near containers filled

with water, next to a kitchen sink, in wet

basements or near a swimming pool.

• Do not immerse the fan, power cord and

power plug into water or any other liquids.

• Do not touch the unit body and the power

plug with wet hands.

• If the fan falls into water, unplug it

before touching it and only then you

may take the fan out of water. Apply to

the nearest authorized service center

for testing or repairing the unit at the

contact addresses given in the war-

ranty certificate and on the website

www.maxwell-products.ru.

• Make sure that the power cord does not

contact with hot surfaces and sharp fur-

niture edges.

• Do not switch the unassembled fan on.

• Do not insert any foreign objects into the

openings of the fan protective grids to

avoid injuries or unit damage.

• Do not touch the rotating blades during

the fan operation.

• Do not place the fan near curtains or

house plants.

• It is not recommended to stay under the

air flow coming from the fan for a long

time (especially for children and elderly

people).

• Do not leave the operating unit unat-

tended.

• Unplug the fan before cleaning and when

you do not use the unit or before moving

it to a new place.

• When unplugging the fan, pull the plug

but not the cord.

• Clean the unit regularly.

• Do not leave children unattended to pre-

vent using the unit as a toy.

• For children safety reasons do not leave

polyethylene bags, used as packaging,

unattended.

ATTENTION! Do not allow children to play

with polyethylene bags or packaging film.

Danger of suffocation!

• Do not allow children to touch the unit

body and the power cord during the unit

operation.

• The unit is not intended for usage by

physically or mentally disabled per-

sons (including children) or by per-

sons lacking experience or knowledge

if they are not under supervision of

a person who is responsible for their

safety or if they are not instructed by

this person on the usage of the unit.

• Do not use the fan if the blades, power

cord or power plug are damaged, if

the fan works improperly, after it was

dropped or was damaged in some other

way.

• Do not attempt to repair the unit. Do not

disassemble the unit by yourself, if any

malfunction is detected or after it was

dropped, unplug the unit and apply to

any authorized service center at the

contact addresses given in the war-

ranty certificate and on the website

www.maxwell-products.ru.

• Transport the unit in the original pack-

age.

• For environment protection do not dis-

card the unit with usual household waste

after its service life expiration; apply to a

specialized center for further recycling.

• Keep the unit in a dry cool place out of

reach of children and disabled persons.

THIS UNIT IS INTENDED FOR HOUSEHOLD

USAGE ONLY

BEFORE THE FIRST USE

After unit transportation or storage at

low temperature keep it for at least three

hours at room temperature.

The fan is supplied disassembled. Do not

switch the fan on until it is completely

assembled.

• Unpack the unit and remove any stickers

that can prevent its operation.

• Check the unit for damages, do not use it

in case of damages.

• Set the supports (17) crosswise on a flat

dry surface.

• Set the telescopic bar (14) on the sup-

ports (17) and fix it with four fastening

screws (18).

• Screw out the clamp (15) by rotating

it counterclockwise. After removing the

clamp (15), set the decorative panel (16)

on the telescopic bar (14). Set the clamp

(15) back to its place by turning it clock-

wise for several times.

• Extend the bar (14) to the desired height

and fix it by tightening the clamp (15)

with a slight effort as you turn it clock-

wise.

• Install the motor unit (12) on the tele-

scopic bar (14) until bumping and fix it

by the clamp (13), do not apply exces-

sive effort when screwing the clamp of

the motor unit (13).

• Set the rear grid (7) on the motor unit

(12) matching the guides on the motor

unit (12) with the corresponding open-

ings on the grid (7).

• The carrying handle (8) on the rear

grid (7) should be turned upwards. Fix

the rear grid (7) on the motor unit (12)

with the plastic nut (6) by screwing it

clockwise until bumping.

• Put the blades (5) on the motor axis (7)

matching the groove on the blades with

the clamp on the motor axis and fix

them with the plastic clamp (2) rotat-

ing it counterclockwise and holding the

blades (5) with your free hand.

• Set the nut and the fixing screw (4) into

the clamp ring (3) sockets.

• Match the front grid (1) and the rear

grid (7), fix them with the clamp ring (3)

and tighten up the clamp ring (3) by turn-

ing the fixing screw (4) tight.

Note! For easy grid assembling of the fan first

install the clamp ring (3) on the rear grid (7)

and tighten up the fastening screw (4) slightly.

Install the bottom part of the front grid (1) on

the clamp ring (3). Then press the bottom part

of the front grid (1) to the clamp ring (3) and

squeezing both grids on the both sides install

the grid (1) under the clamp ring (3). Tighten

the fastening screw (4).

• The fan is ready for operation.

USING THE FAN

• Make sure that the voltage of the mains

corresponds to the operating voltage

of the unit.

• Make sure that the fan is switched off by

pressing the “0” button on the control

panel (10).

• You can change the tilt angle of the

motor unit (12). Turn the clamp coun-

terclockwise to loosen it and set the

desired tilt angle of the motor unit (12),

fix the selected tilt angle turning the

clamp clockwise.

• Insert the power plug into the mains

socket.

• Select the required rotation speed of the

blades (5) by pressing buttons on the

control panel (10):

“0” – fan is switched off;

“1” – low blades rotation speed;

“2” – medium blades rotation speed;

“3” – high blades rotation speed;

• Press the button (11) to switch horizontal

rotation of the motor unit on. To switch

the rotation off, pull the button (11)

upwards.

• Press the “0” button (the fan is switched

off) to switch the unit off.

• Remove the power plug from the mains

socket.

CLEANING AND CARE

• Switch the unit off and unplug it.

• Never use liquid detergents and abra-

sives to clean the fan.

• Wipe the unit with a soft dry cloth.

• To clean the blades, remove the front

grid (1), having previously loosened the

fixing screw (4) and removed the clamp

ring (3). Unscrew the blades clamp (2),

rotating it clockwise and remove the

blades (5).

• Clean the blades (5) with a slightly damp

cloth and then wipe them dry.

• Assemble the fan following the assem-

bling instructions in the «Before the first

use» chapter.

• Do not immerse the motor unit (12), the

power cord and the plug into water or

any other liquids.

STORAGE

• Disconnect the unit from the mains and

clean it.

• If necessary, dismantle the fan. Remove

the clamp ring (3), preliminary loosening

the fastening screw (4), the front grid (1)

and then the blades (5) by rotating the

blades clamp (2) clockwise. Unscrew the

plastic nut (6) turning it counterclock-

wise and remove the rear grid (7) from

the motor unit (12).

• Remove the motor unit (12) from the

telescopic bar (14). Screw out the clamp

(15) by rotating it counterclockwise. After

removing the clamp (15), remove the

decorative panel (16) from the telescopic

bar (14). Unscrew the fastening screws

(18) and disconnect the telescopic bar

(14) from the supports (17). Disconnect

the supports (17).

• Put the fan into the box.

• Keep the unit away from children in a dry

cool place.

DELIVERY SET

Motor unit – 1 pc.

Front grid – 1 pc.

Clamp ring with the screw and nut – 1 pc.

Blade clamp – 1 pc.

Blades – 1 pc.

Rear grid – 1 pc.

Telescopic bar with clamp and decorative

panel – 1 pc.

Supports – 2 pcs.

Screw – 4 pcs.

Instruction manual – 1 pc.

TECHNICAL SPECIFICATIONS

Power supply: 220-240 V ~ 50/60 Hz

Maximum power consumption: 35 W

Diameter: 40 cm (16”)

The manufacturer preserves the right to

change the unit specifications without a

preliminary notification

Unit operating life is 3 years

Guarantee

Details regarding guarantee conditions can

be obtained from the dealer from whom the

appliance was purchased. The bill of sale

or receipt must be produced when making

any claim under the terms of this guarantee.

Напольный вентилятор

MW-3546 BK

RUS

Дата производства изделия указана в серийном номере на табличке с техническими

данными. Серийный номер представляет собой одиннадцатизначное число, первые

четыре цифры которого обозначают дату производства. Например, серийный номер

0606ххххххх означает, что изделие было произведено в июне (шестой месяц) 2006 года.

A production date of the item is indicated in the serial number on the technical data plate.

A serial number is an eleven-unit number, with the first four figures indicating the production

date. For example, serial number 0606ххххххх means that the item was manufactured in June

(the sixth month) 2006.

4 5

ЗАПРЕЩЕНО УТИЛИЗИРОВАТЬ

С БЫТОВЫМ МУСОРОМ.

ОБРАТИТЕСЬ НА СООТВЕТСТВУЮЩИЙ

ПУНКТ ПЕРЕРАБОТКИ ЭЛЕКТРИЧЕСКОГО

И ЭЛЕКТРОННОГО ОБОРУДОВАНИЯ.
