Sven PS-50 [20/22] Operation manual

ENG

Operation Manual

PS-50

• Then switch on the device by long pressing of the button d.

• Switch on an audio signal source.

• Control the master volume level by long pressing of buttons e or f.

• Connect headphones to the jack i (see Fig. 2).

Battery charging

• Connect the device using USB cable (included) to DC IN port k, and then to a USB port of PC or

to 5V DC power unit with output USB jack.

• If the battery is discharged, the indicator a blinks, but if it is charged – the indicator is red.

Notes:

• After using the MSS, mind to unplug the USB cable from a USB port of PC, notebook or 5V

DC power unit.

• To improve sound quality, use the Line-Out output of the sound card.

6. OPERATION MODES

Player Mode

• The system will go to the player mode automatically, if one of carriers (USB Ԝash or micro SD

card)* is inserted into an appropriate jack l or j. Press the button M c on the front panel to

select a desired source, when the MSS is turned on. LED display b will show a selected source

“USB/CARD” and after that the playback time from the beginning. The playback will start auto-

matically. Press buttons f or e short on the front panel to select a track. LED will brieԜy show the

sequence number of a track and after that the playback time from the beginning.

* The operation can be incorrect, when using a micro SD card with the capacity less than 512 Mb.

The time for command processing can be increased, when using a USB Ԝash with the capacity

more than 8 Gb.

Radio Mode

• Use the button ǀ c on the front panel to enter the radio mode when the MSS is on. The display

b will show “FM” symbol and the frequency of a station received.

• Press and hold down the button ǀ c not less than for 2 seconds for the automatic scan and to

store the found stations. The display b will show a frequency during scanning and will show its

sequence number for short time during storing.

AUX Mode

• Use the button ǀ c on the front panel to enter the AUX mode, when the MSS is turned on. The

display b will show “AUX/LINE”.

ON/OFF Mode

• Press and hold down the button d on the front panel to turn on/oԚ the MSS.
