Symbol Meaning

Attention� Important�

A sign certifying that the

product complies with es-

sential requirements of the

EU directives and harmo-

nized EU standards�

Useful information�

Wear protective gloves�

Torque control position:

"Drilling"�

Stepless speed control�

Do not dispose of the power

tool in a domestic waste

container�

DWT

power tool designation

Cordless drills / screwdrivers are designed for hole

drilling in wood, plastic and metal, as well as for screw-

ing in and loosening of threaded fastening elements

(screws, bolts, etc�)�

Power tool

components

Keyless chuck

2 Battery *

3 Battery lock *

4 LED lamp

5 Torque regulator

6 Step speed selector switch

7 On / off switch

8 Reverse switch

9 Ventilation slots

10 Indicators of the state of battery charge *

11 Control button of the state of battery charge *

12 Belt clip *

13 Strap *

14 Screwdriver bit *

15 Power unit *

16 Charger *

17 Screw

18 Magnetic holder *

19 Indicator of the power unit *

20 Indicator (red) *

21 Indicator (green) *

22 Charger label *

* Optional extra

Not all of the accessories illustrated or described

are included as standard delivery.

Installation and regulation

of power tool elements

Before execution of any procedures, centre the re-

verse switch 8.

Do not draw up the fastening elements

too tight to avoid damaging the thread�

Mounting / dismounting / setting-up of

some elements is the same for all power

tool models, in this case specic models

are not indicated in the illustration�

Mounting / replacement of accessories (see g. 1)

With long-term use the drill bit may be-

come very warm; use gloves to remove

it.

• Open the jaws of the keyless chuck 1, rotating its

front part as shown in gure 1.

• Mount / replace the accessory�

• Tighten the keyless chuck 1 without skewing the ac-

cessory as it is shown in gure 1.

Mounting / dismounting of the keyless chuck (see

g. 2-3)

• To mount the keyless chuck 1, carry out the op-

erations in consecutive stages as it is shown in g-

ure 2�

• To dismount the keyless chuck 1, carry out the op-

erations in consecutive stages as it is shown in g-

ure 3�

Attention: keep in mind that in the pro-

cess of mounting / dismounting of the

keyless chuck 1 the screw 17 has a left-

hand thread.

Screwdriver bit / magnetic holder (see g. 4)

For short screwdriver bits use the magnetic holder 18

for their reliable xing (see g. 4).

A magnetic holder 18 is not needed for extended

screwdriver bits 14 (specially purposed for screw-

drivers)�

Charging procedure

of the power tool battery

Initial operating of the power tool

The power tool is supplied with a partially charged

battery 2. Before the rst use, the battery 2 must

be fully charged.
