Charging process (see g. 5-6)

• Centre the reverse switch 8�

• Press the battery lock 3 and remove the battery 2

(see g. 5.1, 6.1).

[ABS-12 L, ABS-14,4 L]

Warning! Do not work under the charging

status!

• Connect the power unit 15 to the power supply�

• Insert plug of the power unit 15 in socket of the bat-

tery 2 (see g. 5.2).

• Disconnect the power unit 15 from the battery 2 and

mount battery 2 in the power tool�

• Disconnect the power unit 15 from power supply�

[ABS-18 L]

• Insert battery 2 into charger 16 (see g. 6.2).

• Connect the charger 16 to the power supply�

• Disconnect the charger 16 from power supply after

charging�

• Remove the battery 2 from the charger 16 and

mount battery 2 in the power tool (see g. 6.3).

Charger indicators (see g. 5, 7)

[ABS-12 L, ABS-14,4 L]

Indicators 10 (of the battery 2) and indicator 19 (of the

power unit 15) inform about charging process of the

battery 2 (see g. 5).

• Indicator 19 lights green, power unit 15 is not con-

nected to the battery 2 - power unit 15 is connected to

the power network (ready for charging)�

• Indicator 19 lights red, power unit 15 is connected to

the battery 2, indicators 10 lights red (one by one) - the

battery 2 is being charged�

• Indicator 19 lights green, power unit 15 is connected

to the battery 2, all indicators 10 lights red - the bat-

tery 2 is fully charged� Some time later indicators 10

will be turns off to save energy�

• Indicator 19 lights green, power unit 15 is connected

to the battery 2, indicators 10 not lights - the charging

process of the battery 2 is terminated because of its

failure� Replace the faulty battery 2, its further use is

prohibited�

[ABS-18 L]

Charger indicators 20 and 21 inform of the battery 2

charging process� Signals of the indicators 20 and 21

are shown on the label 22 (see g. 7.1-7.3).

• Fig� 7�1 - (the green indicator 21 is on, the battery 2

is not inserted in the charger 16) - the charger 16 is

connected to the power network (ready for charging)�

• Fig� 7�2 - (the red indicator 20 is on, the battery 2

is inserted in the charger 16) - the battery 2 is being

charged�

• Fig� 7�3 - (the green indicator 21 is on, the battery 2

is inserted in the charger 16) - the battery 2 is fully

charged�

In the process of charging the battery 2

and the charger 16 become hot, it is a

normal process.

Switching the power

tool on / off

Make sure that the reverse switch 8 is not centred,

this blocks on / off switch 7.

Switching on:

Press on / off switch 7.

Switching off:

Release the on / off switch 7�

Design features

of the power tool

Battery (see g. 8)

The battery 2 is protected by the safety system against

deep discharge� In case of complete discharge, the

power tool is automatically switched off� Attention:

do not try to switch on the power tool when the

protection system is activated the battery 2 can be

damaged.

With the push of the button 11 the indicators 10 show

the state of charge of the battery 2 (see g. 8).

Temperature protection

The temperature protection system enables to auto-

matically deactivate the power tool in case of excess

load or when the temperature of the battery 2 is ex-

ceeding 70°C� The system guarantees protection of

the power tool from damage in case of noncompliance

with the operation conditions�

LED lamp

When the on / off switch 7 is pushed, the LED lamp 4

is automatically switched on that allows to carry out

works in low light conditions�

Torque regulator

Rotate the regulator 5 in order to set one of the 20

torque values most suitable for the work performed�

It is recommended to set the torque

regulator 5 into the position "Drill" to perform

drilling�

Stepless speed adjustment

Speed is controlled from 0 to maximum by

pressing force of on / off switch 7� Weak

pressing results in low revolutions, which

enable a smooth power tool switch-on�

Step speed selector switch

Attention: one can only change the revo-

lutions per minute range after the engine

fully stops.

In order to choose the "1" gear, move the switch 5

back� This mode is used for the fastening of screws or

for large diameter hole drilling�

In order to choose the "2" gear, move the switch 5

forward� This mode is used for speed drilling of small

diameter holes�
