10

1. The water heater is connected to a water

supply network with a pressure of at least

0.02 MPa, maximum 0.7 MPa

2. To connect the water heater to the water

supply, pipes with a diameter of G1/2 are

used.

3. When connecting pipes, use rubber seals

on the threaded pipe ends to prevent

leakage.

4. Screw the safety valve onto the inlet

pipe, marked in blue and with a sign of

the direction of water ow, so that the

water ow matches the direction of the

arrow on the valve body. On the pressure

relief hole of the safety valve, put a drain

pipe to drain water (it may appear when

heated) into the sewer.

5. The safety valve is installed on the cold

water pipe (marked with a blue ring).

(maximum pressure 0.7 MPa / 7.0 Bar). If

the water pressure in the line exceeds 6

Bar, a pressure reducing valve should be

installed.

6. Connect the water heater with the valve

mounted to the water supply network -

install a shut-o valve at the water supply

point.

7. Connect the desired number of

consumption points to the outlet marked

in red.

8. Open the shut-o valve and one of the

collapsible valves. After lling the tank, as

evidenced by the outow of water from

the collapsible tap, close the collapsible

tap and check the tightness of all

connections.

Water supply connection

Please use the accessories provided by the

manufacturer to install the water heater.

The electric water heater must not be

mounted on the wall before you make

sure that the bracket is securely and rmly

installed. Otherwise, the electric water

heater may fall o the wall, resulting in

damage and even serious injury or injury.

When determining the points for holes

for anchor bolts, a free space between the

bottom of the water heater and the oor

should be at least 0.6 m.

Mounting

1. Determine the points for the bolt

holes (determined according to the

specication of the instrument you have

chosen). Drill two holes of appropriate

depth in the wall using a drill bit that ts

the bolts, install the mounting bracket,

and then hang the electric water heater.

2. Attach the power outlet to the wall. The

socket requirements are as follows: 220-

240V / 10A, single-phase, three-wire. It is

recommended to place the socket on the

right side above the water heater.

The water pressure in the water heater

corresponds to the water pressure in the

water main. If the pressure in the line

exceeds 0.7 MPa, then a pressure reducer

should be installed in front of the water

heater so that the pressure does not

exceed 0.7 MPa.

In places or on a wall where water can

enter, the installation height of the

electrical outlet must be at least 1.8 m.

Attention!

Attention!

Attention!
