- 5 -
www.fubag.ru
Omperator's anual
6. Charging battery in vehicle
- PositionAC and DC cords to reduce risk of damage by hood, door, or moving engine part.
Stay clear of fan blades, belts, pulleys, and other parts that can cause injury to persons.
Check polarity of battery posts. POSITIVE (POS P +) battery post usually has larger diameter than
NEGATIVE (NEG N -) post.
Determine which post of battery is grounded (connected) to the chassis.
If negative post is grounded to chassis (as in most vehicles), connect POSITIVE (RED) clip from
battery charger to POSITIVE(P05 P +) ungrounded post of battery. Connect NEGATIVE (BLACK)
clip to vehicle chassis or engine block away from battery. Do not connect clip to carburetor, fuel lines,
or sheet-metal body parts. Connect to heavy gauge metal part of the frame or engine block
If positive post is grounded to the chassis, connect NEGATIVE (BLACK) clip from battery charger to
NEGATIVE (NEG N -) ungrounded post of battery. Connect POSITIVE (RED) clip to vehicle chassis
or engine block away from battery. Do not connect clip to carburetor, fuel lines, or sheet-metal body
parts. Connect to a heavy gauge metal part of the frame or engine block.
When disconnecting charger, disconnect AC cord first, remove clip from vehicle chassis, and then
remove clip from battery terminal.
Do not charge the battery while the engine is operating.
-
-//
//
-
//
.
//
-
-
7. Charging battery out of vehicle
When charging battery out of vehicle, take care to determine the battery type. To reduce risk of a
spark near battery, follow these steps when battery is outside vehicle.
WARNING:Aspark near the battery may cause battery explosion.
WARNING: When removing battery from vehicle or boat, disconnect grounded pole first. When
disconnecting, make sure all accessories are off, so as not to cause an arc.
NOTE: A marine (boat) battery must be removed and charged on shore. (To charge on board
requires special equipment designed for marine use.)
WARNING: When reinstalling battery, attach the ground post first.
Check polarity of battery posts. Battery case will be marked by each post: POSITIVE (POS P +)
and NEGATIVE (NEG N -). NOTE: The positive battery post usually has a larger diameter than the
negative post.
Connect POSITIVE (RED) charger clip to POSITIVE (POS P +) post battery. Connect NEGTIVE
(BLACK) charger clip to NEGTIVE (BLACK N -) post battery.
Rock clip back and forth to make good connection.
WARNING: Do not face battery when making final connection.
Plug chargerAC cord into a 220 volt main supply.
Switch on charger and then select amperage.
WARNING: Be sure area around battery is well ventilated while battery is being charged. Gas can
be forcefully blown away by using a piece of card board or other non-metallic material as a fan.
When battery is fully charged, unplug charger from AC power source first then remove clip from
Negative post, and remove clip from Positive battery post.
Clean and store battery charger.
- //
//
-//
//
-
-
-
-
