English | 25

enced through ambient conditions or the nature of the wall, there may be a hazard

even though the measuring indicator(i) does not indicate an object in the sensor

area, no audio signal sounds and the light-up ring(1) lights up green.

Operating Modes

You can achieve the best possible measuring results by selecting the correct operating

mode. You can achieve the maximum detection depth for metal objects in the Metal op-

erating mode. You can achieve the maximum detection depth for live wires in the Power

cable operating mode.

The selected operating mode is always shown by the green operating mode

indicator(4).

Drywall operating mode

Drywall operating mode is designed for detecting wooden and metal objects in dry walls.

To activate Drywall operating mode, press the Drywall operating mode button(11). The

operating mode indicator(4) above the Drywall operating mode button will light up

green.

As soon the measuring tool is positioned on the surface to be examined, the light-up

ring(1) will light up green, indicating readiness to measure.

In Drywall operating mode, all available objects will be detected and displayed:

(c)

Non-metallic, e.g. wooden beams

(d)

Non-magnetic, but metal, e.g. copper pipe

(e)

Magnetic, e.g. reinforcing steel

(f)

Live, e.g. power lines

Note: In the Drywall operating mode, other objects, e.g.water-filled plastic pipes, will be

also displayed in addition to wooden and metal objects and live wires. For these objects,

the Non-metallic object indicator(c) will appear in the display.

Nails and screws in the base material may result in wooden beams being identified as

metal objects.

If the display indicates a continuously high amplitude of the measuring indicator(i) and

the fine scale(j), re-start the measuring process again by placing the measuring tool

elsewhere on the surface.

If the light-up ring(1) does not indicate readiness to measure when positioned on the

surface to be examined, the measuring tool has not been able to detect the base material

correctly.

– Press and hold the Drywall operating mode button(11) until the light-up ring(1)

lights up green. Take the measurement as normal.
