ENGLISHen

Protect the device from water and moisture.

Do not expose to rain.

WARNING! Unintentional startup can

cause serious injuries. Before

cleaning or maintenance: Switch off

the machine, remove the safety key and remove the

battery packs.

Use battery packs with the same

capacity.

Use battery packs that have the same

amount of charge.

See pages 2 and 3.

1Cable holder

2 On/off switch

3Switch bracket

4 Handle (for pushing and steering the machine)

5Handlebars

6 Grass collection bag

7 Rear ejection flap

8Mulching key

9Carry handle

10 Verticutters (for mowing near edges)

11 Lever (central cutting height adjustment)

12 Protective cover (battery packs)

13 Levers of the quick clamps

14 Quick clamps

15 Screws

16 Wing nuts

17 Fill level window

18 Ejection opening

19 Battery pack release button

20 Safety key

21 Battery packs *

22 Capacity and signal indicator *

23 Capacity indicator button *

24 Locking screw for blade

25 Washer

26 Blades

27 Blade holder (the semi-circular holes in the

blade must match the semi-circles of the

machine)

*equipment-specific

6.1 Assemble the handle,

adjusting the handle height

WARNING! Do not damage the cables when

folding and unfolding.

Fig. A: Unfold handlebars (5)

1. Fold handlebars (5) backwards.

2. Fold the levers (13) of the quick clamps (14) .

Note:

If the clamping strength is set inappropriately:

Open lever (13). Twist quick clamp (14) . Close

lever (13) again and check clamping strength. If

necessary, repeat procedure.

Fig. B: Assemble handle (4) and set handle

height

3. Attach the bar ends of the handle (4), as shown,

onto the handlebars (5).

4. Set the desired handle height by aligning the

handle (4) in one of the three positions (1..2..3..).

5. Insert the screws (15) left and right.

Note:

Make sure that the screws (15) (on both

sides) are in the same position (1..2..3..).

Note:

Mount the wing nuts (16) on the inside so that

they do not get caught during mowing (e.g. on

branches or hedges).

6. Screw the wing nuts (16) onto the screws (15)

and tighten.

7. Fix the cable in the cable holders (1).

6.2 Preparation for grass collection,

mulching

Collect grass / mount grass collection basket.

Fig. C

1. Unfold the rear ejection flap (7) upwards and

hold.

2. Ejection opening (18) must be empty. If

necessary remove mulching key (8) (lift and put

aside).

3. Hold grass collection basket (6) on its handle

and attach the hook as shown.

4. Close the rear ejection flap (7) .

Mulching / mounting the mulching key. Fig. D

1. Unfold the rear ejection flap (7) upwards and

hold.

2. Remove the grass collection basket (6) .

3. Hold the mulching key (8) on its handles and

insert into the ejection chute. (Push in until the

stop and press downwards. Ensure that the

mulching key has engaged in the designated

recesses .)

4. Close the rear ejection flap (7) .

6.3 Set depth of cut.

Fig. on page 2.

Slightly pull the lever (11) outwards and shift the

guide to the desired position. Let engage in the

desired position.

Adjust the cutting height to the height of the grass to

be cut.

Note:

For an optimal mowing result:

Cut off no more than one third of the grass height.

When mowing tall grass, reduce the speed at which

the mower is pushed.

Note:

For an optimal mulching result, the lawn

should be mulched regularly. There should be a

maximum of 2 cm of grass cuttings as mulch

(recommendation: position 2 or position 3).

6.4 Battery pack

Fig. E

Charge the battery pack before use.

Recharge the battery pack if performance

diminishes.

5. Overview

6. Initial Operation
