ENGLISH en

4.2 Special safety instructions for cordless

machines:

Remove the battery pack from the machine before

making any adjustments, changing tools,

maintaining or cleaning.

Protect battery packs from water and

moisture!

Do not expose battery packs to fire!

Do not use faulty or deformed battery packs!

Do not open battery packs!

Do not touch contacts or short-circuit battery packs!

A slightly acidic, flammable fluid may leak

from defective Li-ion battery packs!

If battery fluid leaks out and comes into

contact with your skin, rinse immediately

with plenty of water. If battery fluid leaks out

and comes into contact with your eyes, wash them

with clean water and seek medical attention

immediately!

Transport of li-ion battery packs:

The shipping of li-ion battery pack is subject to laws

related to the carriage of hazardous goods (UN

3480 and UN 3481). Inform yourself of the currently

valid specifications when shipping li-ion battery

packs. If necessary, consult your freight forwarder.

Certified packaging is available from Metabo.

- Only send the battery pack if the housing is intact

and no fluid is leaking. Remove the battery pack

from the machine for sending. Prevent the

contacts from short-circuiting (e.g. by protecting

them with adhesive tape).

See page 2.

1Spindle

2 Thumb-wheel for gear selection *

3Trigger switch

4Locking button for continuous activation *

5 Speed preselection wheel *

6Handles

7Locking button

8 Battery pack release button *

9 Capacity indicator button *

10 Capacity and signal indicator *

11 Battery pack*

* depending on the model / features

6.1 For mains powered machines only

Before plugging in, check that the rated mains

voltage and mains frequency, as stated on the

rating label, match with your power supply.

Always install an RCD with a maximum trip

current of 30 mA upstream

6.2 For cordless machines only

Battery pack

Charge the battery pack before use (11).

If performance diminishes, recharge the battery

pack.

The ideal storage temperature is between 10°C and

30°C.

"Li-Power, LiHD" lithium-ion battery packs have a

capacity and signal indicator (10):

- Press the (9) button, the LEDs indicate the charge

level.

- If one LED is flashing, the battery pack is almost

flat and must be recharged.

Removing and inserting the battery pack

Remove:

Press the battery pack release button (8)

and remove battery pack (11).

To insert:

Slide the battery pack (11) in until it

engages.

7.1 Tool change

Attach the stirrer:

Screw the stirrer by hand into the spindle (1).

Remove the tool:

Hold the spindle (1) using an open-ended wrench

and fix the stirrer using a second open-ended

wrench.

7.2 Select the gear (depending on features)

Select the required gear by rotating the thumb

wheel (2).

Change speed when the machine is in the process

of running down (briefly switch it on and off).

I = 1. st gear (low speed, high torque)

II = 2. nd gear (high speed)

7.3 Presetting the speed (depending on

features)

Select the maximum speed using the preselection

wheel (5).

(Press in the trigger (3) to increase the rotational

speed.)

7.4 On/Off switch, modifying the speed

Switching on, speed: Press the trigger (3) .

Press in the trigger to increase the rotational speed.

5. Overview

6. Commissioning

7. Use
