FEATURES

Single module size with switched neutral line

Breaking capacitay 6 kA

Simple replace MCB with RCBO in the same place

Functionaly on minimum supply voltage 90 V

The terminals provide to use also saving busbars

Method of DIN rail mounting enables an easy removal of single RCBO without

disconnecting units from busbars

Assembly to a 35 mm wide mounting rail in accordance with EN 60715

RCBOs ARE USED IN APPLICATIONS WHERE THERE IS THE NEED TO COMBINE

PROTECTION AGAINST OVERCURRENTS (OVERLOAD AND SHORT-CIRCUIT)

AND PROTECTION AGAINST EARTH LEAKAGE CURRENTS.

THEY ARE USED IN CIRCUITS WITH AN INCREASED REQUIREMENTS

REGARDING TOUCH VOLTAGE (BATHROOMS, EVENT HALLS, SCHOOLS,

HOSPITALS, SWIMMING POOLS, MARINAS, DISTRIBUTION CABINETS, MOBILE

HOUSES, ETC.)

6-2

RFI1

RESIDUAL CURRENT CIRCUIT BREAKERS

WITH OVERCURRENT PROTECTION

Residual current circuit breakers with overcurrent prozection up to 32 A ................

Connections ................................................................................................

Example - Ordering data .................................................................

Technical characteristics .................................................................

Dimensions ......................................................................................

page 6-2

page 6-5

page 6-3

page 6-4

page 6-5

ORDERING DATA
