• Turning the bolt 26 in or out, make the sides of

the 90° setsquare join the surfaces of saw blade 3 and

base plate 11 tightly�

• Holding bolt 26, tighten lock-nut 27�

Initial operating

of the power tool

Always use the correct supply voltage: the power sup-

ply voltage must match the information quoted on the

tool identication plate.

Switching the power

tool on / off

Switching on:

In order to switch on the power tool, push lock-off but-

ton 6 and while holding it in position, push switch but-

ton 7�

Switching off:

In order to switch off the power tool, release switch

button 7�

Dust suction during

the power tool operation

Dust suction allows reducing dust concen-

tration in the air and prevents its accumula-

tion at the workplace�

While operating the power tool, always use a

vacuum cleaner suitable for collecting process-gener-

ated dust� A special adapter is used to join the vacuum

cleaner to coupler 1�

Recommendations

on the power tool operation

Cutting depth setting (see g. 8)

Before starting the operation, adjust sawing depth de-

pending on the work piece thickness� The best cutting

edge quality is achieved when the projected part of

saw blade 3 does not exceed tooth height�

• Loosen xing lever 21 (see g. 8).

• Set required sawing depth on scale 20, lifting or low-

ering the power tool body�

• Tighten xing lever 21�

Cutting angle setting (see g. 9-11)

The power tool enables smooth cutting angle adjust-

ment within 0°- 45° range�

• Loosen:

• xing wing nut 28 for HKS12-54, HKS12-63,

HKS15-65 (see g. 9-10);

• two xing screws 9 for HKS18-75, HKS18-85

(see g. 11).

• Set required cutting angle on scale 8, changing pow-

er tool body inclination angle�

• Tighten:

• xing wing nut 28 for HKS12-54, HKS12-63,

HKS15-65;

• two xing screws 9 for HKS18-75, HKS18-85�

Remember that during inclined cutting

the cutting depth shown on scale 20

does not correspond with actual values.

Cutting marks (see g. 12)

• Cutting mark 13 shows saw blade 3 position during

vertical cutting (see g. 12).

• Cutting mark 12 shows saw blade 3 position during

cutting at 45° angle (see g. 12).

Make trial sawing to avoid errors.

Sawing (see g. 13)

The efciency and the quality of cutting

operations depends on the state and

the form of saw blade 3 teeth, there-

fore proper selection of saw blade is

extremely important depending on the material

being processed and the type of works being per-

formed.

• Make sure that the work piece is safely xed face

down, because the quality of bottom cutting edge is

always better�

• Switch on the power tool before saw blade 3 touch-

es the work piece� Let saw blade 3 gain maximal rotat-

ing speed�

• Smoothly move the power tool forward without

bending or pushing�

• Never press the tool - sawing requires certain time�

Extra pressure will overload the power tool rather than

facilitate the operation�

• Use additional supports when cutting large sheets

(chipboards, etc�) to avoid bending and possible saw

blade 3 blocking (see g. 13).

Cutting with parallel guide (see g. 14)

Parallel guide 14 enables cutting along existing direct

work piece edge, and producing equally wide stripes�

• Loosen xing screw 10 of parallel guide 14 (see

g. 14).

• Move parallel guide 14 to set a required work piece

width�

• Tighten xing screw 10 of parallel guide 14�

Power tool maintenance /

preventive measures

Before carrying out any works on the power tool it

must be disconnected from the mains

Cleaning of the power tool

An indispensable condition for a safe long-term exploi-

tation of the power tool is to keep it clean� Regularly

ush the power tool with compressed air thought the

ventilation slots 17�

After-sales Service and Application Service

Our after-sales service responds to your questions

concerning maintenance and repair of your product as

well as spare parts� Information about service centers,
