English | 13

Bosch Power Tools 3 609 929 C07 | (19.5.11)

Additional safety warnings

Wear safety goggles.

f Use appropriate detectors to determine if utility lines

are hidden in the work area or call the local utility com-

pany for assistance. Contact with electric lines can lead

to fire and electric shock. Damaging a gas line can lead to

explosion. Penetrating a water line causes property dam-

age.

f Secure the workpiece. A workpiece clamped with clamp-

ing devices or in a vice is held more secure than by hand.

f The power tool is not suitable for stationary operation.

For example, it may not be clamped in a vice or fastened on

a workbench.

f Do not open the battery. Danger of short-circuiting.

Protect the battery against heat, e. g., against

continuous intense sunlight, fire, water, and

moisture. Danger of explosion.

f In case of damage and improper use of the battery, va-

pours may be emitted. Provide for fresh air and seek

medical help in case of complaints. The vapours can irri-

tate the respiratory system.

f Use the battery only in conjunction with your Bosch

power tool. This measure alone protects the battery

against dangerous overload.

f Use only original Bosch batteries with the voltage list-

ed on the nameplate of your power tool. When using oth-

er batteries, e. g. imitations, reconditioned batteries or

other brands, there is danger of injury as well as property

damage through exploding batteries.

Product Description and Specifica-

tions

Read all safety warnings and all instruc-

tions. Failure to follow the warnings and in-

structions may result in electric shock, fire

and/or serious injury.

While reading the operating instructions, unfold the graphics

page for the machine and leave it open.

Intended Use

The machine is designed for grinding and deburring metal us-

ing corundum grinding tools, as well as for working with sand-

ing wheels.

Product Features

The numbering of the product features refers to the illustra-

tion of the machine on the graphics page.

1 Collet chuck

2 Clamping nut

3 Grinder spindle

4 Spindle collar

5 On/Off switch

6 Battery unlocking button*

7 Battery*

8 Handle (insulated gripping surface)

9 Button for charge-control indicator*

10 Battery charge-control indicator*

11 Open-end spanner on the grinder spindle*

12 Open-end spanner applied to clamping nut*

*Accessories shown or described are not part of the standard de-

livery scope of the product. A complete overview of accessories

can be found in our accessories program.

Noise/Vibration Information

Measured sound values determined according to EN 60745.

Typically the A-weighted noise levels of the product are:

Sound pressure level 77 dB(A); Sound power level 88 dB(A).

Uncertainty K =3 dB.

Wear hearing protection!

Vibration total values a

(triax vector sum) and Uncertainty K

determined according to EN 60745:

Surface grinding (with wheel diameter of 25 mm):

=3,5m/s

, K=1,5 m/s

The vibration emission level given in this information sheet

has been measured in accordance with a standardised test

given in EN 60745 and may be used to compare one tool with

another. It may be used for a preliminary assessment of expo-

sure.

The declared vibration emission level represents the main ap-

plications of the tool. However if the tool is used for different

applications, with different accessories or poorly maintained,

the vibration emission may differ. This may significantly in-

crease the exposure level over the total working period.

An estimation of the level of exposure to vibration should also

take into account the times when the tool is switched off or

when it is running but not actually doing the job. This may sig-

nificantly reduce the exposure level over the total working pe-

riod.

Identify additional safety measures to protect the operator

from the effects of vibration such as: maintain the tool and the

accessories, keep the hands warm, organisation of work pat-

terns.

Technical Data

Straight grinder GGS 18 V-LI

Professional

Article number

3 601 JB5 3..

Rated voltage

V= 18

Rated speed

min

-1

22000

Collet chuck diameter, max.

mm 8

Spanner size of

–clamping nut

–grinder spindle

Please observe the article number on the type plate of your machine.

The trade names of the individual machines may vary.
