a
c
e
b
g
f
h
i
j
d
Remote control
a : On/Off button
b : Bluetooth activation button
c VOL+/-: volume up/down
d AUX: AUX stereo input selection
e : sound on/off
f : previous track (in the Bluetooth mode)
g : next track (in the Bluetooth mode)
h : play/pause (in the Bluetooth mode)
i TRE.+/-: treble level up/down
j BASS+/-: bass level up/down
Notes:
• Before operating the remote control, extract the battery,
remove the film protecting the battery from discharge
during transportation, and insert the battery back into the
remote control.
• Use the remote control at an angle of no more than 30°,
no more than 7 meters away.
• Direct the remote control at the IR receiver display on the
subwoofer.
• If the remote control does not work, check the battery or
replace the discharged battery with a new one.
• Remove the battery from the remote control if you don’t
intend to use it for a long time (more than a week).
5. PREPARATION AND OPERATION
Speaker placement
• Place the speakers symmetrically to the listener at least one meter away. The subwoofer emits non-
directional sound, therefore it can be located in any place of the room where it sounds the best.
• Place MSS far away from monitors and TV sets, as insignificant image distortion in these supersensitive
devices is possible.
MSS сonnecting and control
MS-350BL speaker system can be connected to virtually any audio devices: MP3/CD players, PCs,
laptops, etc. (see connection diagram in Fig. 4).
• Before making any connections, make sure the MSS is off and unplugged. Then connect the sub-
woofer OUTPUT e jack to the satellites using the built-in audio cables.
• To connect the MSS to a PC, МР3/CD player or a telephone, use the signal cable h built into the
subwoofer. Insert the mini-jack of the signal cable (green) into the line-out port of your PC sound
card or your MP3/CD player, and the mini-jack of the microphone cable (pink) – into the mic input
port of your sound card, as shown in Fig. 4.
• Сonnect the subwoofer to the mains outlet with the power cord d.
• Turn on the subwoofer power supply using the ON/OFF switch (c, ON position) on the sub-
woofer rear panel.
Fig. 3. Remote control
ENG
20
2.1 Multimedia Speaker
System with Bluetooth
