*2019522*
2019522 English 23
Identify additional safety measures to protect the operator from the effects of noise and/or vibration, for
example: maintaining the power tool and accessory tools, keeping the hands warm, organization of work
patterns.
Noise emission values
SCM 22-A
Sound power level (L
WA
)
104 dB(A)
Uncertainty for the sound power level (K
WA
)
3 dB(A)
Sound pressure level (L
pA
)
93 dB(A)
Uncertainty for the sound pressure level (K
pA
)
3 dB(A)
Total vibration
SCM 22-A
Vibration emission value for sawing in metal (A
h, M
)
0.82 m/s²
Uncertainty (K)
1.5 m/s²
5 Operation
5.1 Preparations at the workplace
5.1.1 Charging the battery
1. Before charging the battery, read the operating instructions for the charger.
2. Make sure that the contacts on the battery and the contacts on the charger are clean and dry.
3. Use an approved charger to charge the battery.
5.1.2 Inserting the battery
CAUTION
Risk of injury by short circuit or falling battery!
▶ Before inserting the battery, make sure that the contacts on the battery and the contacts on the product
are free of foreign matter.
▶ Make sure that the battery always engages correctly.
1. Charge the battery fully before using it for the first time.
2. Push the battery into the battery holder until it engages with an audible click.
3. Check that the battery is seated securely.
5.1.3 Removing the battery
1. Press the release buttons on the battery.
2. Pull the battery out of its holder in the device.
5.1.4 Removing the saw blade 2
WARNING
Risk of burning injury. A hot accessory tool, clamping flange or clamping screw and the sharp edges of the
saw blade present hazards.
▶ Wear protective gloves when changing saw blades.
1. Remove the battery.
2. Insert the hex key into the saw blade clamping screw.
3. Press the spindle lockbutton and hold it in this position.
4. Turn the saw blade clamping screw with the hex key until the spindle lock button engages fully.
5. Release the clamping screw by turning the hex key in the direction of the direction-of-rotation arrow.
6. Remove the clamping screw from the outer clamping flange.
7. Open the pivoting guard by swinging it to the side and then remove the saw blade.
If necessary, the mounting flange can be removed for cleaning.
Printed: 06.06.2019 | Doc-Nr: PUB / 5142664 / 000 / 04
