24 English 2019522
*2019522*
5.1.5 Fitting the saw blade 3
CAUTION
Risk of damage! Unsuitable or incorrectly fitted saw blades may damage the saw.
▶ Only use blades which are suitable for this saw. Observe the direction-of-rotation arrow on the saw
blade.
▶ Use only saw blades equipped with a rated maximum permissible speed that is at least as high as the
maximum speed stated on the product.
Check that the blade to be fitted complies with the technical requirements and that it is well
sharpened. A sharp saw blade is an essential requirement for a perfect cut.
1. Clean the mounting flange and the clamping flange.
2. Fit the mounting flange onto the arbor the right way round.
3. Open the pivoting guard.
4. Fit the new saw blade.
Observe the direction-of-rotation arrow on the saw blade and on the power tool. They must
correspond.
5. Fit the outer clamping flange the right way round.
6. Insert the clamping screw.
7. Insert the hex key into the saw blade clamping screw.
8. Press the spindle lock button.
9. Secure the clamping flange with the clamping screw by turning the hex key in the direction opposite to
the direction-of-rotation arrow.
➥ The spindle lock button engages.
10. Before using the power tool, check that the saw blade is correctly seated and tightened securely.
5.1.6 Adjusting the cutting depth 4
1. Release the cutting depth adjustment clamping lever.
2. Lift the product in a scissor movement and set the desired cutting depth by closing the clamping lever.
5.1.7 Emptying the chip collector 5
WARNING
Risk of injury! Hot or sharp metal cuttings / chips present a hazard.
▶ Wear protective gloves when emptying the chip collector.
1. Remove the battery.
2. Pull the chip collector away from the tool to the rear.
3. Swing the two halves of the chip collector apart and empty out its contents.
4. Push the chip collector onto the guard until in engages in position.
5.2 Work
5.2.1 Switching on
▶ While pressing the safety lock, switch the product on by pressing the on/off button.
5.2.2 Switching off
▶ Release the on/off switch to stop the machine.
5.2.3 Sawing along a line 6
Secure the workpiece to prevent movement.
Position the workpiece so that the saw blade is free to rotate beneath it.
Check to ensure that the on/off switch on the power tool is in the “off” position.
Position the forward section of the saw’s base plate on the workpiece but do not bring the blade into
contact with the workpiece.
Printed: 06.06.2019 | Doc-Nr: PUB / 5142664 / 000 / 04
