2. Screw the clamping screw into the base plate, leaving enough space to slide the fence through.

3. Slide the fence guide under the clamping screw.

4. Set the desired cutting width.

5. Tighten the clamping screw.

5.1.10 Fitting the guide rail adapter 8

The saw can be equipped with a guide rail adapter which is available as an accessory.

1. Remove the battery.

2. Remove the fence, if one is fitted.

3. Fit the base plate into the side retaining channels of the guide rail adapter.

4. Fully insert the base plate into the guide rail adapter.

5. Lock the guide rail adapter by pressing in the two sliders as far as they will go.

5.2 Work

5.2.1 Switching on

▶ Press and hold down the switch-on interlock and switch the product on by pressing the on/off button.

5.2.2 Switching off

▶ Release the on/off switch to stop the machine.

5.2.3 Longitudinal cuts at 0°

1. Place the saw on the guide rail so that the rib fits into the groove in the adapter.

2. Switch the product on. → page 26

3. Guide the product along the rail and through the workpiece at a suitable speed.

5.2.4 Longitudinal cuts at angles up to 50°

1. Set the angle.

2. Switch the product on. → page 26

3. Guide the saw along the guide rail with the outer edge of the guide rail adapter on the rib on the guide

rail. The saw blade will otherwise collide with the guide rail.

5.2.5 Making cuts at an angle across the surface of the workpiece

1. Position the guide rail with the zero mark at the edge of the workpiece and then pivot the rail until the

desired angle shown on the angle scale is opposite the zero mark. The cutting angle indicated is the

angle of deviation from a straight, right-angled cut.

2. Secure the guide rail with the two screw clamps.

3. Switch the product on. → page 26

4. Guide the product along the rail and through the workpiece at a suitable speed.

5.2.6 Using the saw without a dust and chip removal system

1. Check that the sawdust is ejected without obstruction.

2. If required, the hose connector can be removed from the blade guard by slackening the hex socket screw

with the hex key supplied with the product.

5.3 Procedure if the chip / dust channel is blocked

1. Pull the battery out of the product to the rear.

2. Clean the chip / dust channel.

Remove the saw blade if necessary.

3. Check for misalignment or binding of moving parts, breakage of parts and any other condition that may

affect operation of the product.
