*2233926*
2233926 English 9
ATTENTION! When cutting or slitting with abrasive cutting discs always use the standard guard with
the additional front cover, or a fully enclosing dust hood.
Discs
Type Application Designation Material
Abrasive cutting disc Cutting, slitting ACD Metal
Diamond cutting disc Cutting, slitting DC-TP, DCD (SPX,
SP, P)
Mineral
Abrasive grinding disc Rough grinding AGD, AFD, AND Metal
Diamond grinding disc Rough grinding DGCW (SPX, SP,
P)
Mineral
Wire brushes Wire brushes 3CS, 4CS, 3SS,
4SS
Metal
Diamond core bit Drilling in tiles DDM14 Mineral
Abrasive resin-fiber disc Rough grinding AP-D Metal
Suitability of discs for the equipment used
Item Equipment ACD AGD,
AFD,
AND
DG-CW
(SPX, SP,
P)
DC-TP,
DC-D
(SPX, SP,
P)
AP-D 3CS, 4CS,
3SS, 4SS,
DD-M14
A Guard X X X X X X
B Front cover (in
combination with
A)
X — — X — —
C Dust hood (grinding)
DGEX 125⁄5"
— — X — — —
D Dust hood (cutting)
DCEX 125⁄5"C (in
combination with A)
— — — X — —
E DC-EX 125/5"M dust
hood for slitting
— — — X — —
F DCEX SL adapter (in
combination with E)
— — — X — —
G Side handle X X X X X X
H Clamping nut X X X X — —
I Clamping flange X X X X — —
J
Kwik lock (optional
instead of H)
X X — X — —
K Clamping nut for
abrasive resin-fiber
disc
— — — — X —
L Support plate — — — — X —
5 Technical data
AG 4S-A22125
Rated voltage
21.6 V
Rated speed
8,500 /min
Maximum disc diameter
125 mm
Weight in accordance with EPTA procedure 01
3.1 kg
Drive spindle thread
M14
Spindle length
22 mm
Printed: 29.08.2019 | Doc-Nr: PUB / 5476814 / 000 / 02
