2233926 English 11

6.2 Inserting the battery

CAUTION

Risk of injury by short circuit or falling battery!

▶ Before inserting the battery, make sure that the contacts on the battery and the contacts on the product

are free of foreign matter.

▶ Make sure that the battery always engages correctly.

1. Charge the battery fully before using it for the first time.

2. Push the battery into the battery holder until it engages with an audible click.

3. Check that the battery is seated securely.

6.3 Removing the battery

1. Press the battery release buttons.

2. Remove the battery from the tool.

6.4 Fitting the side handle

▶ Screw the side handle into one of the threaded bushings provided.

6.5 Fitting or removing the guard

CAUTION

Risk of injury. The accessory tool may be hot or have sharp edges.

▶ Wear protective gloves when fitting, removing or adjusting the accessory tool or other parts and when

troubleshooting.

▶ Observe the instructions for fitting the applicable guard.

6.5.1 Installing standard guard 6

The guard is equipped with locating lugs that ensure only guards of a type suitable for use with the

power tool can be fitted. The locating lugs of the guard fit into the guard mount on the power tool.

1. Fit the guard onto the drive spindle collar so that the two triangular marks on the guard and on the power

tool are in alignment.

2. Press the guard onto the drive spindle collar.

3. Press the guard release button and then rotate the guard until it engages in the desired position.

➥ The guard release button jumps back.

6.5.2 Adjusting standard guard

▶ Press the guard release button and then rotate the guard until it engages in the desired position.

6.5.3 Removing standard guard

1. Press the guard release button and then rotate the guard until the triangular marks on the guard and the

power tool are in alignment.

2. Remove the guard.

6.6 Fitting or removing the front cover 7

The front cover, when used, is clipped onto the guard.

1. Position the front cover with the closed side on the standard guard and push it on until it engages.

2. To remove it, release the catch for the front cover and then lift the front cover away from the standard

guard.
