16 | English

The lithium-ion battery is protected against deep discharge

by "Electronic Cell Protection (ECP)". A protective circuit

switches the radio off when the rechargeable battery is

drained.

u Do not switch the radio back on after it has been

switched off by the protective circuit. This can damage

the battery.

Replacing a Rechargeable Battery

Disengage the locking lever(13) of the battery cover and

open the battery cover(12) flap.

To remove a rechargeable battery, press the battery release

button(16) and pull the rechargeable battery out of the bat-

tery compartment. Do not use force to do this.

To insert a rechargeable battery, push it into the battery

holder(14) such that the connections of the rechargeable

battery are in line with the connections of the battery holder.

Allow the rechargeable battery to engage.

Close the battery cover(12) and lock it.

Battery Charge Indicator

When the rechargeable battery is inserted, you can see the

state of charge of the battery(17) in the display. When the

rechargeable battery is removed, you can see this on the

battery itself.

Battery Charge Indicator in the Display

The battery charge indicator(i) will appear in the display as

soon as a rechargeable battery with sufficient voltage is in-

serted and the radio is not connected to the mains supply via

the power supply(20).

Display Capacity

80−100%

60−80%

40−60%

20−40%

5−20%

0−5%

Battery Charge Indicator on the Rechargeable Battery

If the rechargeable battery is removed from the radio, its

state of charge may be indicated by the green LEDs of the

battery charge indicator on the rechargeable battery.

Press the button for the battery charge indicator or to

show the state of charge.

If no LED lights up after pressing the button for the battery

charge indicator, then the battery is defective and must be

replaced.

Battery model GBA 18V...

LEDs Capacity

3× continuous green light 60−100%

LEDs Capacity

2× continuous green light 30−60%

1× continuous green light 5−30%

1× flashing green light 0−5%

Battery model ProCORE18V...

LEDs Capacity

5× continuous green light 80−100%

4× continuous green light 60−80%

3× continuous green light 40−60%

2× continuous green light 20−40%

1× continuous green light 5−20%

1× flashing green light 0−5%

Operation with power supply (see figureA)

u Use only the power supply listed in the technical data.

This is the only this way to ensure proper operation of the

radio.

u Pay attention to the mains voltage. The voltage of the

power source must match the voltage specified on the

type plate of the power supply.

Open the protective cap of the connector

compartment(15). Insert the plug-in connector(21) of the

power supply into the connection socket(22) (DCIN18V).

Connect the power supply to the mains supply.

After removing the plug-in connector(21), reattach the pro-

tective cap of the connector compartment(15) to protect

against dirt/debris.

Changing the button cell

To save the time and other settings on the radio, a button

cell must be inserted as a back-up battery.

Before using the radio for the first time, remove the protect-

ive strip of the inserted button cell.

Disengage the locking lever(13) of the battery cover and

open the battery cover(12) flap.

If required, remove the rechargeable battery(17).

Pull the protective film out under the cover(18) of the but-

ton cell.

Replace the button cell once the radio no longer saves the

time and the display gets weaker.

To do this, turn the cover(18) of the button cell anticlock-

wise (e.g. with a coin) and remove the cover. Insert a new

button cell.

When doing so, ensure that the polarity is correct according

to the illustration on the inside of the cover(18).

1 609 92A 7XU | (27.05.2022) Bosch Power Tools
