English | 17

Put the cover(18) of the button cell back on and turn it

firmly clockwise. The cover is only securely locked if the

markings on the cover and padlock symbol are facing each

other.

u Take the button cell out of the radio if you are not us-

ing it for a prolonged period of time. When stored in the

radio for longer periods, the button cell can corrode and

discharge itself.

Operation

u Protect the radio against direct water contact. Water

entering the radio increases the risk of an electric shock.

u Keep the battery cover and the protective cap of the

connector compartment closed if possible. The closed

covers protect the radio against water and dust.

Audio Operation

Switching On and Off

To switch on the radio, press the on/off button(2). The

display(1) is activated and the audio source that was set the

last time the radio was turned off is played back.

The display(1) is illuminated for a few seconds each time a

button is pressed.

To switch off the radio, press the on/off button(2) again.

The current setting of the audio source will be saved.

Adjusting the Volume

After the radio is switched on, the volume is always set to

low.

To increase the volume, turn the on/off button(2) clock-

wise; to reduce the volume, turn it anticlockwise.

The volume setting<VL> or<Volume> will appear on the

display for a few seconds with a value between 0 and 30. Be-

fore adjusting or changing a radio station, set the volume to a

low setting; before starting an external audio source, set the

volume to a medium setting.

To switch off the sound, you can briefly press the mute

button(8). To switch on the sound again, either briefly press

the mute button again or turn the on/off button(2) clock-

wise.

The volume can be changed at any time. If the menu function

is activated, the display will return to the menu a few

seconds after you have changed the volume.

The radio switches off automatically after 19min, if during

this time:

– The volume on the radio is set to 0,

– The radio is muted or

– The volume on the playback device (e.g. smartphone) is

set to 0.

Selecting an Audio Source

To select an audio source, press the source button(7) until

the required internal or external audio source is shown in the

display:

– DAB/DAB2: Digital radio via DAB+ (GPB18V‑2SC),

– FM/FM2: Analogue radio via FM,

– AUX: External audio source (e.g. smartphone) via the

3.5‑mm socketAUXIN(24) in the connector

compartment(15),

– : External audio source (e.g. smartphone) via the

Bluetooth® connection.

The current audio source can be seen on the audio source

indicator(b) or Bluetooth® indicator(a).

The audio sourcesDAB andDAB2 (GPB18V‑2SC), as well

asFM andFM2, do not differ in their functionality; they offer

only additional preset spaces.

Setting/saving DAB+ radio stations (GPB18V‑2SC)

To select the audio source DAB+ radio stations, press the

source button(7) untilDAB orDAB2 appears on the audio

source indicator(b).

After a short initialisation, the last set radio station will be

played back.

Each station name appears on the top line of the multi-func-

tion indicator(k). The additional information shown on the

bottom line of the multi-function indicator can be set with

the menu function.

– To switch the station, turn the source button(7) until

the required station is shown in the display. Press the

source button(7) to confirm the selection. The radio will

switch to the selected station.

Alternatively, you can press the seek button (scan

down)(10) or the seek button (scan up)(9) to switch the

station. The radio will switch to the next available station

(in alphabetical order, either descending or ascending).

– To save a set station, press the preset button(5) of the

required storage space until the number of the storage

space appears in the storage space indicator(c).

If the four storage spaces of theDAB audio source are oc-

cupied, then switch to theDAB2 audio source, in which

four further storage spaces are available, by pressing the

source button(7). Please note that you must reset the re-

quired station after switching to save the change.

– To start playback of a saved station, briefly press one of

the preset buttons(5). The number of the storage space

will appear on the storage space indicator(c). If required,

switch between audio sourcesDAB andDAB2 by press-

ing the source button(7), to allow you to go back to all

saved stations.

Note: If the radio signal is weak, <Weak Signal> will appear

on the multi-function indicator(k). In this case, you can

manually start the DAB+ station search.

To do this, either select<Auto Scan> from the menu or

press the seek button (scan down)(10) and the seek button

(scan up)(9) simultaneously. After the station search is

complete, four stations will be saved in preset spaces 1 to 4.

Stations that have already been saved will be overwritten

here.

If no DAB+ radio stations can be found,<No DAB Station–

Please Auto Scan> will appear on the multi-function

indicator(k).

Bosch Power Tools 1 609 92A 7XU | (27.05.2022)
