3.2.2 Shortening the profile

– If two Vario shower channels are to be joined together,

one of the base units must be shortened by at least

210 mm

Chapter 3.2.2 „Shortening the profile“

on page 23.

– End closing pieces, connection pieces and connection

pieces 90° must not be shortened.

Calculate profile length, also see

Chapter 3.2.1 „Calculating the

profile length in niche installation“ on page 22.

Transfer the length of the profile onto the shower channel.

INFO! Depending on the installation situation, the shower

channel can be shortened on one or both sides. The position

of the drain may be chosen freely. However, the distance

from the middle of the drain to the end of the profile may not

be less than 150 mm.

Shorten the profile with a hacksaw.

The saw blade must not be wider than 1.5 mm.

150

Handling

Advantix Vario base unit, for Advantix Vario shower channel, can be cut to length continuously 24 from 50
